root@truenas[/var/log]# smartctl -a /dev/da3
smartctl 7.2 2020-12-30 r5155 [FreeBSD 12.2-RELEASE-p14 amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke,
www.smartmontools.org
=== START OF INFORMATION SECTION ===
Model Family: Seagate Archive HDD (SMR)
Device Model: ST8000AS0002-1NA17Z
Serial Number: Z84010E2
LU WWN Device Id: 5 000c50 07a08ac8f
Firmware Version: AR13
User Capacity: 8,001,563,222,016 bytes [8.00 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5980 rpm
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ACS-3 T13/2161-D revision 3b
SATA Version is: SATA 3.1, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Sat Aug 13 19:24:57 2022 CEST
SMART support is: Available - device has SMART capability.
SMART support is: Enabled
=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED
See vendor-specific Attribute list for marginal Attributes.
General SMART Values:
Offline data collection status: (0x82) Offline data collection activity
was completed without error.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 0) seconds.
Offline data collection
capabilities: (0x7b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 1) minutes.
Extended self-test routine
recommended polling time: ( 954) minutes.
Conveyance self-test routine
recommended polling time: ( 2) minutes.
SCT capabilities: (0x30a5) SCT Status supported.
SCT Data Table supported.
SMART Attributes Data Structure revision number: 10
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000f 116 099 006 Pre-fail Always - 113138888
3 Spin_Up_Time 0x0003 091 089 000 Pre-fail Always - 0
4 Start_Stop_Count 0x0032 098 098 020 Old_age Always - 2566
5 Reallocated_Sector_Ct 0x0033 100 100 010 Pre-fail Always - 0
7 Seek_Error_Rate 0x000f 074 060 030 Pre-fail Always - 56198755968
9 Power_On_Hours 0x0032 084 084 000 Old_age Always - 14047
10 Spin_Retry_Count 0x0013 100 100 097 Pre-fail Always - 0
12 Power_Cycle_Count 0x0032 099 099 020 Old_age Always - 1344
183 Runtime_Bad_Block 0x0032 100 100 000 Old_age Always - 0
184 End-to-End_Error 0x0032 100 100 099 Old_age Always - 0
187 Reported_Uncorrect 0x0032 100 100 000 Old_age Always - 0
188 Command_Timeout 0x0032 100 100 000 Old_age Always - 0
189 High_Fly_Writes 0x003a 100 100 000 Old_age Always - 0
190 Airflow_Temperature_Cel 0x0022 066 036 045 Old_age Always In_the_past 34 (2 63 34 24 0)
191 G-Sense_Error_Rate 0x0032 100 100 000 Old_age Always - 0
192 Power-Off_Retract_Count 0x0032 100 100 000 Old_age Always - 1150
193 Load_Cycle_Count 0x0032 097 097 000 Old_age Always - 6757
194 Temperature_Celsius 0x0022 034 064 000 Old_age Always - 34 (0 16 0 0 0)
195 Hardware_ECC_Recovered 0x001a 116 099 000 Old_age Always - 113138888
197 Current_Pending_Sector 0x0012 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0010 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x003e 200 200 000 Old_age Always - 0
240 Head_Flying_Hours 0x0000 100 253 000 Old_age Offline - 7991 (115 250 0)
241 Total_LBAs_Written 0x0000 100 253 000 Old_age Offline - 35009442500
242 Total_LBAs_Read 0x0000 100 253 000 Old_age Offline - 587473543856
SMART Error Log Version: 1
No Errors Logged
SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 14042 -
# 2 Extended offline Aborted by host 90% 14042 -
# 3 Short offline Completed without error 00% 14021 -
# 4 Short offline Completed without error 00% 13997 -
# 5 Short offline Completed without error 00% 13973 -
# 6 Short offline Completed without error 00% 13949 -
# 7 Short offline Completed without error 00% 13925 -
# 8 Short offline Completed without error 00% 13901 -
# 9 Short offline Completed without error 00% 13879 -
#10 Short offline Completed without error 00% 13873 -
#11 Short offline Completed without error 00% 13849 -
#12 Short offline Completed without error 00% 13825 -
#13 Short offline Completed without error 00% 13801 -
#14 Short offline Completed without error 00% 13777 -
#15 Short offline Completed without error 00% 13753 -
#16 Short offline Completed without error 00% 13729 -
#17 Short offline Completed without error 00% 13705 -
#18 Short offline Completed without error 00% 13681 -
#19 Short offline Completed without error 00% 13657 -
#20 Short offline Completed without error 00% 13633 -
#21 Short offline Completed without error 00% 13592 -
SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.
