By start use iSCSI service on FreeNAS, core system start pull errors - device: ATA error count increased if used ACHI of Intel C236

lexxai

lexxai

Dabbler
Joined
Nov 9, 2016
Messages
33
FreeNAS 11.2-U1

Detect that when on remote system I start use attached iSCSI disk for write
On FreeNAS system have start messaging about error disk (device: ATA error count increased ...)
but cable checked, reattached, and errors on differ disk can be.

If use SAMBA services, NOT HAVE any errors on disk.
S.M.A.R.T. status of all disks is OK.

Disks SATA, WD RED 2TB. Connected to MB ASUS P10S-E/4L (Intel® C236), 32G RAM ECC.
ZFS, RAID Z2, 8 disks.

Error " device: ATA error" start only if used iSCSI connection and then error continue fill log until POWER CYCLE of MB.
Reset of system not help for remove error "device: ATA error", only after POWER CYCLE of MB can help to use normally system.

Must sector size by always be 512 bytes for iscsi vol ?

Scrub on zpool ok.

when start: zpool scrub
have diag message some times: interrupt storm detect on "irq265:"; throttling interrupt source
Code:
vmstat -i
interrupt                          total       rate
irq265: ahci0                   11696109      10534

dmesg |grep ahci0
ahci0: <Intel Sunrise Point AHCI SATA controller> port 0xf050-0xf057,0xf040-0xf043,0xf020-0xf03f mem 0xde510000-0xde511fff,0xde51e000-0xde51e0ff,0xde51d000-0xde51d7ff at device 23.0 on pci0
ahci0: AHCI v1.31 with 8 6Gbps ports, Port Multiplier not supported
ahcich0: <AHCI channel> at channel 0 on ahci0
ahcich1: <AHCI channel> at channel 1 on ahci0
ahcich2: <AHCI channel> at channel 2 on ahci0
ahcich3: <AHCI channel> at channel 3 on ahci0
ahcich4: <AHCI channel> at channel 4 on ahci0
ahcich5: <AHCI channel> at channel 5 on ahci0
ahcich6: <AHCI channel> at channel 6 on ahci0
ahcich7: <AHCI channel> at channel 7 on ahci0



ATA Status Error only if used iSCSI connection.:
Code:
Jan  2 21:33:40 nas (ada5:ahcich5:0:0:0): Retrying command
Jan  2 21:33:43 nas (ada7:ahcich7:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 0d d8 42 6a 40 78 00 00 00 00 00
Jan  2 21:33:43 nas (ada7:ahcich7:0:0:0): CAM status: ATA Status Error
Jan  2 21:33:43 nas (ada7:ahcich7:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
Jan  2 21:33:43 nas (ada7:ahcich7:0:0:0): RES: 41 10 d8 42 6a 00 78 00 00 00 00
Jan  2 21:33:43 nas (ada7:ahcich7:0:0:0): Retrying command
Jan  2 21:33:43 nas (ada6:ahcich6:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 02 b1 97 6a 40 78 00 00 00 00 00
Jan  2 21:33:43 nas (ada6:ahcich6:0:0:0): CAM status: ATA Status Error
Jan  2 21:33:43 nas (ada6:ahcich6:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
Jan  2 21:33:43 nas (ada6:ahcich6:0:0:0): RES: 41 10 b1 97 6a 00 78 00 00 00 00
Jan  2 21:33:43 nas (ada6:ahcich6:0:0:0): Retrying command
Jan  2 21:33:43 nas (ada4:ahcich4:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 01 66 98 6a 40 78 00 00 00 00 00
Jan  2 21:33:43 nas (ada4:ahcich4:0:0:0): CAM status: ATA Status Error
Jan  2 21:33:43 nas (ada4:ahcich4:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
Jan  2 21:33:43 nas (ada4:ahcich4:0:0:0): RES: 41 10 66 98 6a 00 78 00 00 00 00
Jan  2 21:33:43 nas (ada4:ahcich4:0:0:0): Retrying command
Jan  2 21:33:43 nas (ada2:ahcich2:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 02 d1 93 69 40 78 00 00 00 00 00
Jan  2 21:33:43 nas (ada2:ahcich2:0:0:0): CAM status: ATA Status Error
Jan  2 21:33:43 nas (ada2:ahcich2:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
Jan  2 21:33:43 nas (ada2:ahcich2:0:0:0): RES: 41 10 d1 93 69 00 78 00 00 00 00
Jan  2 21:33:43 nas (ada2:ahcich2:0:0:0): Retrying command
Jan  2 21:33:47 nas (ada5:ahcich5:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 01 20 59 6a 40 78 00 00 00 00 00
Jan  2 21:33:47 nas (ada5:ahcich5:0:0:0): CAM status: ATA Status Error
Jan  2 21:33:47 nas (ada5:ahcich5:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
Jan  2 21:33:47 nas (ada5:ahcich5:0:0:0): RES: 41 10 20 59 6a 00 78 00 00 00 00
Jan  2 21:33:47 nas (ada5:ahcich5:0:0:0): Retrying command


SMART of DISK
Code:
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   184   184   021    Pre-fail  Always       -       3783
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       87
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   100   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   075   075   000    Old_age   Always       -       18511
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       87
16 Total_LBAs_Read         0x0022   000   200   000    Old_age   Always       -       48335351388
183 Runtime_Bad_Block       0x0032   100   100   000    Old_age   Always       -       0
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       62
193 Load_Cycle_Count        0x0032   200   200   000    Old_age   Always       -       73
194 Temperature_Celsius     0x0022   126   111   000    Old_age   Always       -       21
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

Last edited:
lexxai

lexxai

Dabbler
Joined
Nov 9, 2016
Messages
33
dlavigne said:
Were you able to resolve this?
Click to expand...
No solution still, for more testing wait new RAID Controller SAS 3008 (Supermicro AOC-S3008L-L8I).
I wish that with same disk , same configuration OS but with SAS 3008 all should be OK.

lexxai

lexxai

Dabbler
Joined
Nov 9, 2016
Messages
33
With RAID Controller SAS 3008 (Supermicro AOC-S3008L-L8I). New cables.
IT mode v.16.00.01.

Code:
Num   Ctlr            FW Ver        NVDATA        x86-BIOS         PCI Addr
----------------------------------------------------------------------------
0  SAS3008(C0)  16.00.01.00    0e.01.30.28    08.37.00.00     00:01:00:00


Situation much better.
But once was CAM ERROR...

Code:
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 0 lun 0 (pass0,da0)
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 1 lun 0 (pass1,da1)
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 2 lun 0 (pass2,da2)
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 3 lun 0 (pass3,da3)
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 4 lun 0 (pass4,da4)
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 5 lun 0 (pass5,da5)
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 6 lun 0 (pass6,da6)
<ATA WDC WD2004FBYZ-0 RR04>        at scbus0 target 7 lun 0 (pass7,da7)


+--------------------------------------------------------------------------------+
+                       camcontrol inquiry da6 @1547598866                       +
+--------------------------------------------------------------------------------+
pass6: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
pass6: Serial Number      WD-WMC6N0E2XXXX
pass6: 600.000MB/s transfers, Command Queueing Enabled
debug finished in 0 seconds for camcontrol inquiry da6


Code:
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): SYNCHRONIZE CACHE(10). CDB: 35 00 00 00 00 00 00 00 00 00 length 0 SMID 699 Aborting command 0xfffffe000108fcd0
Jan 16 02:16:17 nas mpr0: Sending reset from mprsas_send_abort for target ID 6
Jan 16 02:16:17 nas smartd[4154]: Device: /dev/da6 [SAT], failed to read SMART Attribute Data
Jan 16 02:16:17 nas     (pass6:mpr0:0:6:0): ATA COMMAND PASS THROUGH(16). CDB: 85 08 0e 00 d0 00 01 00 00 00 4f 00 c2 00 b0 00 length 512 SMID 264 terminated ioc 804b loginfo 31130000 scsi 0 state c xfer 0
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c4 f7 00 01 00 00 length 131072 SMID 561 terminated ioc 804b loginfo 31130000 scsi 0 state c xfer 0
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c3 f7 00 01 00 00 length 131072 SMID 488 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c4 f7 00 01 00 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c2 f7 00 01 00 00 length 131072 SMID 970 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c3 f7 00 01 00 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c1 f7 00 01 00 00 length 131072 SMID 332 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c2 f7 00 01 00 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c0 f7 00 01 00 00 length 131072 SMID 903 terminated ioc 804b loginfo 31130000 scsi 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c1 f7 00 01 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bf f7 00 01 00 00 length 131072 SMID 214 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 c0 f7 00 01 00 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:    (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 be f7 00 01 00 00 length 131072 SMID 740 terminated ioc 804b loginfo 31130000 scmpr0:0:si 0 state c xfer 0
Jan 16 02:16:17 nas 6:0): Retrying command
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bd f7 00 01 00 00 length 131072 SMID 139 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bf f7 00 01 00 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bd 1e 00 00 d9 00 length 111104 SMID 409 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:si 0 state c xfer 0
Jan 16 02:16:17 nas 0): Retrying command
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bc 1e 00 01 00 00 length 131072 SMID 931 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 be f7 00 01 00 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bb 1e 00 01 00 00 length 131072 SMID 720 terminated ioc 804b loginfo 31130000 sc(da6:si 0 state c xfer 0
Jan 16 02:16:17 nas mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 ba 1e 00 01 00 00 length 131072 SMID 514 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bd f7 00 01 00 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b9 1e 00 01 00 00 length 131072 SMID 869 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b8 1e 00 01 00 00 length 131072 SMID 921 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bd 1e 00 00 d9 00
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b7 1e 00 01 00 00 length 131072 SMID 747 terminated ioc 804b loginfo 31130000 sc(da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bc 1e 00 01 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 bb 1e 00 01 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 ba 1e 00 01 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b9 1e 00 01 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas si 0 state c xfer 0
Jan 16 02:16:17 nas     (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b6 1e 00 01 00 00 length 131072 SMID 391 terminated ioc 804b loginfo 31130000 scsi 0 state c xfer 0
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b8 1e 00 01 00 00
Jan 16 02:16:17 nas mpr0: (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas Unfreezing devq for target ID 6
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b7 1e 00 01 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b6 1e 00 01 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: CCB request completed with an error
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): SYNCHRONIZE CACHE(10). CDB: 35 00 00 00 00 00 00 00 00 00
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): CAM status: Command timeout
Jan 16 02:16:17 nas (da6:mpr0:0:6:0): Retrying command
Jan 16 02:16:18 nas (da6:mpr0:0:6:0): READ(10). CDB: 28 00 11 00 b6 1e 00 01 00 00
Jan 16 02:16:18 nas (da6:mpr0:0:6:0): CAM status: SCSI Status Error
Jan 16 02:16:18 nas (da6:mpr0:0:6:0): SCSI status: Check Condition
Jan 16 02:16:18 nas (da6:mpr0:0:6:0): SCSI sense: UNIT ATTENTION asc:29,0 (Power on, reset, or bus device reset occurred)
Jan 16 02:16:18 nas (da6:mpr0:0:6:0): Retrying command (per sense data)

lexxai

lexxai

Dabbler
Joined
Nov 9, 2016
Messages
33
With new RAID Controller SAS 3008 and new cables, work next day w/o errors.
When I reconnect HDD (4 hdd on mini-HD SAS cable) back to MB SATA and reuse one new cable with MB then errors back on use iSCSI service.

4 HDD on Intel C236 ACHI and 4 HDD on SAS 3008 (IT mode):
Code:
Intel C236 ACHI: (4 HDD)
ada0 at ahcich0 bus 0 scbus1 target 0 lun 0
ada0: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada0: Serial Number WD-WMC6N0E637FX
ada0: 600.000MB/s transfers (SATA 3.x, UDMA6, PIO 8192bytes)
ada1 at ahcich1 bus 0 scbus2 target 0 lun 0
ada1: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada1: Serial Number WD-WMC6N0E250AX
ada2 at ahcich2 bus 0 scbus3 target 0 lun 0
ada2: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada2: Serial Number WD-WMC6N0E2VVPX
ada3 at ahcich3 bus 0 scbus4 target 0 lun 0
ada3: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada3: Serial Number WD-WMC6N0E2U33X
ada3: 1907729MB (3907029168 512 byte sectors)

SAS 3008 IT mode: (4 HDD)
da0 at mpr0 bus 0 scbus0 target 4 lun 0
da0: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
da0: Serial Number WD-WMC6N0E4C37X
da0: 600.000MB/s transfers
da1 at mpr0 bus 0 scbus0 target 5 lun 0
da1: Serial Number WD-WMC6N0E46UHX
da1: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
da2 at mpr0 bus 0 scbus0 target 6 lun 0
da2: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
da2: Serial Number WD-WMC6N0E4PWYX
da3 at mpr0 bus 0 scbus0 target 7 lun 0
da3: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
ada3: Serial Number WD-WMC6N0E2U33X

(ada0:ahcich0:0:0:0): FLUSHCACHE48. ACB: ea 00 00 00 00 40 00 00 00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 51 (DRDY SERV ERR), error: 04 (ABRT )
(ada0:ahcich0:0:0:0): RES: 51 04 00 00 00 40 00 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 06 7f 57 44 40 62 00
00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada0:ahcich0:0:0:0): RES: 41 10 7f 57 44 00 62 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 2a 2f 96 45 40 32 00
00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada0:ahcich0:0:0:0): RES: 41 10 2f 96 45 00 32 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 2b 08 ae 45 40 32 00
00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada0:ahcich0:0:0:0): RES: 41 10 08 ae 45 00 32 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada1:ahcich1:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 2b 08 ae 45 40 32 00
00 00 00 00
(ada1:ahcich1:0:0:0): CAM status: ATA Status Error
(ada1:ahcich1:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada1:ahcich1:0:0:0): RES: 41 10 08 ae 45 00 32 00 00 00 00
(ada1:ahcich1:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 01 bb 58 44 40 62 00
...........
(ada1:ahcich1:0:0:0): ATA status: 51 (DRDY SERV ERR), error: 10 (IDNF )
(ada1:ahcich1:0:0:0): RES: 51 10 a3 5b 44 40 62 00 00 01 00
(ada1:ahcich1:0:0:0): Retrying command
ahcich0: Timeout on slot 28 port 0
ahcich0: is 00000000 cs 10000000 ss 00000000 rs 10000000 tfd c0 serr
00000000 cmd 0004dc17



And swap 4 HDD by 4 HDD:
Code:
Intel C236 ACHI: (4 HDD)
ada0 at ahcich0 bus 0 scbus1 target 0 lun 0
ada0: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada0: Serial Number WD-WMC6N0E4C37X
ada1 at ahcich1 bus 0 scbus2 target 0 lun 0
ada1: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada1: Serial Number WD-WMC6N0E46UHX
ada2: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada2: Serial Number WD-WMC6N0E4PWYX
ada3 at ahcich3 bus 0 scbus4 target 0 lun 0
ada3: <WDC WD2004FBYZ-01YCBB1 RR04> ACS-3 ATA SATA 3.x device
ada3: Serial Number WD-WMC6N0E5YZDX

SAS 3008 IT mode: (4 HDD)
da0 at mpr0 bus 0 scbus0 target 4 lun 0
da0: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
da0: Serial Number WD-WMC6N0E637FX
da1 at mpr0 bus 0 scbus0 target 5 lun 0
da1: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
da1: Serial Number WD-WMC6N0E250AX
da3 at mpr0 bus 0 scbus0 target 7 lun 0
da3: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
da3: Serial Number WD-WMC6N0E2U33X
da2 at mpr0 bus 0 scbus0 target 6 lun 0
da2: <ATA WDC WD2004FBYZ-0 RR04> Fixed Direct Access SPC-4 SCSI device
da2: Serial Number WD-WMC6N0E2VVPX


(ada0:ahcich0:0:0:0): FLUSHCACHE48. ACB: ea 00 00 00 00 40 00 00 00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 51 (DRDY SERV ERR), error: 04 (ABRT )
(ada0:ahcich0:0:0:0): RES: 51 04 00 00 00 40 00 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 06 7f 57 44 40 62 00
00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada0:ahcich0:0:0:0): RES: 41 10 7f 57 44 00 62 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 2a 2f 96 45 40 32 00
00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada0:ahcich0:0:0:0): RES: 41 10 2f 96 45 00 32 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 2b 08 ae 45 40 32 00
00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada0:ahcich0:0:0:0): RES: 41 10 08 ae 45 00 32 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada1:ahcich1:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 2b 08 ae 45 40 32 00
00 00 00 00
(ada1:ahcich1:0:0:0): CAM status: ATA Status Error
(ada1:ahcich1:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada1:ahcich1:0:0:0): RES: 41 10 08 ae 45 00 32 00 00 00 00
(ada1:ahcich1:0:0:0): Retrying command
(ada0:ahcich0:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 01 bb 58 44 40 62 00
00 00 00 00
(ada0:ahcich0:0:0:0): CAM status: ATA Status Error
(ada0:ahcich0:0:0:0): ATA status: 41 (DRDY ERR), error: 10 (IDNF )
(ada0:ahcich0:0:0:0): RES: 41 10 bb 58 44 00 62 00 00 00 00
(ada0:ahcich0:0:0:0): Retrying command
(ada1:ahcich1:0:0:0): WRITE_FPDMA_QUEUED. ACB: 61 01 ba 58 44 40 62 00
00 00 00 00

Last edited:
lexxai

lexxai

Dabbler
Joined
Nov 9, 2016
Messages
33
ASUS support answer :
The FreeNAS operating system may not work correctly with disk controllers. Please install a compatible operating system, the list of which is listed in the file: https://dlcdnets.asus.com/pub/ASUS/...7.1661101004.1547565468-1555637543.1547565468
Click to expand...


For information:
Found that other MB with Intel C236 - Supermicro X11SSH-F have FreeBSD 11.1 in OS Compatibility Chart.
https://www.supermicro.com/support/resources/OS/C236.cfm

Last edited:
D

dcarbone

Cadet
Joined
Dec 7, 2018
Messages
3
I believe I am running into the same issue with my own c236-based SuperMicro X11SAE-O board and 11.2u1. I have two SSD's in a zfs mirror as my boot pool on the c236, and this has not caused any issue. As soon as I added two spinning disks, I immediately started seeing those same errors.

On my 9305-16i, the same drives that throw errors work flawlessly. I have to assume the onboard controller just does not play nice with spinning disks + freebsd. Really not sure.

Last edited:
You must log in or register to reply here.

Similar threads

S
  • Locked
ATA error count increased
Replies
4
Views
5K
danb35
danb35
M
  • Locked
S.M.A.R.T. ATA error count increased
Replies
7
Views
7K
joeschmuck
joeschmuck
A
  • Locked
Another, is my drive dead question?
Replies
8
Views
1K
wblock
wblock
A
  • Locked
ATA error count increased from 0 to 1
Replies
1
Views
2K
Steve Brown
S
S
  • Locked
ATA error count increased from 0 to 1
Replies
7
Views
2K
spurdo1337
S
Top
