Hi All,
I am using iSCSI and Fiber channel QLogic 2564 HBA's. My FC switches are old 4gbps Brocade 4900's and I am wondering if there is any tweaking to do on the iSCSI side for more threads or more buffers?
Hi All,
I am using iSCSI and Fiber channel QLogic 2564 HBA's. My FC switches are old 4gbps Brocade 4900's and I am wondering if there is any tweaking to do on the iSCSI side. My zpool is a 3 way mirror of 3tb 7200rpm SAS drives with presently 21 drives in the pool for 7 stripes soon to be 14 stripes.
I am using VMware 7.0.2 Build 17867351 and TrueNAS Core 12.0-U4 with Dual E5-2660 v2 processors with 192GB of RAM. The VM is a windows server 2019 with 8 cores and 8gb ram.
Here is my /etc/ctl.conf
portal-group "default" {
}
lun "truenas1" {
ctl-lun "0"
path "/dev/zvol/vol1/vmware/tns1"
blocksize "512"
option "pblocksize" "0"
serial "246e968dc068000"
device-id "iSCSI Disk 246e968dc068000 "
option "vendor" "TrueNAS"
option "product" "iSCSI Disk"
option "revision" "0123"
option "naa" "0x6589cfc00000070d6306ae680db96d14"
option "insecure_tpc" "on"
option "rpm" "7200"
}
target "iqn.2005-10.org.superstore1.ctl:tns1" {
alias "tns1"
lun "0" "tns1"
}
I am using iSCSI and Fiber channel QLogic 2564 HBA's. My FC switches are old 4gbps Brocade 4900's and I am wondering if there is any tweaking to do on the iSCSI side for more threads or more buffers?
Hi All,
I am using iSCSI and Fiber channel QLogic 2564 HBA's. My FC switches are old 4gbps Brocade 4900's and I am wondering if there is any tweaking to do on the iSCSI side. My zpool is a 3 way mirror of 3tb 7200rpm SAS drives with presently 21 drives in the pool for 7 stripes soon to be 14 stripes.
I am using VMware 7.0.2 Build 17867351 and TrueNAS Core 12.0-U4 with Dual E5-2660 v2 processors with 192GB of RAM. The VM is a windows server 2019 with 8 cores and 8gb ram.
Here is my /etc/ctl.conf
portal-group "default" {
}
lun "truenas1" {
ctl-lun "0"
path "/dev/zvol/vol1/vmware/tns1"
blocksize "512"
option "pblocksize" "0"
serial "246e968dc068000"
device-id "iSCSI Disk 246e968dc068000 "
option "vendor" "TrueNAS"
option "product" "iSCSI Disk"
option "revision" "0123"
option "naa" "0x6589cfc00000070d6306ae680db96d14"
option "insecure_tpc" "on"
option "rpm" "7200"
}
target "iqn.2005-10.org.superstore1.ctl:tns1" {
alias "tns1"
lun "0" "tns1"
}
