Version:
TrueNAS-12.0-U8
Hardware:
Dell PowerEdge T620 (Rack Version)
2 x Intel(R) Xeon(R) CPU E5-2630 v2 @ 2.60GHz
128GB DDR3 PC3L 1333MHz (4 x 32GB DIMMs)
12 x 3.5" drive bays
1 x SuperMicro AOC-SHG3-4M2P PCI-E 3.0 carrier card for up to four NVMe M.2 SSDs
1 x Dell 27NFF LSI 9207-8i SATA/SAS 6Gb/s PCI-E 3.0 IT Mode HBA
1 x Dell FD0CG LSI 9207-8e SATA/SAS 6Gb/s PCI-E 3.0 IT Mode HBA
1 x Dell 0XYT17 Intel X520-SR2 10GbE (vLANs for management, NFS & SMB network shares)
1 x EMC KTN-STL3 DAE 15 x 3.5" enclosure
Fan control script
Boot Pool:
2 x Intel 80GB SSD DC S3500 Series
Storage Pool 1: Media storage
vdev 1 8 x Western Digital Red 4TB WD40EFRX 3.5" SATA 5400 RPM (RAIDZ2) (Initial vdev 2014)
vdev 2 8 x Seagate Iron Wolf 4TB ST4000VN008 3.5" SATA 5400 RPM (RAIDZ2) (Added vdev 2020)
Storage Pool 2: Backups & file storage
vdev 1 - 6 x SEAGATE ST33000650SS 3TB NL-SAS (RAIDZ2)
log - 2 x HITACHI HUSRL401 NEO100 100GB SSD SAS SLOG
Storage Pool 3: ESXi VM storage
vdev 1 - 2 x PNY 2TB NVMe (MIRROR)
log - 1 x Intel Optane 900p 280GB NVMe SLOG
cache - 1 x SAMSUNG MZ1LV480HCHP-000MU 480GB NVMe L2ARC
