I destroyed the dataset and re-created it. During that process, Truenas sent an alert about a disk issue so that's been replaced.
now I'm getting about 101k IOPS and 400ish MB/s for reads and writes.
writes
Code:
fio --filename=test --direct=1 --rw=randrw --randrepeat=0 --rwmixread=100 --iodepth=128 --numjobs=12 --runtime=60 --group_reporting --name=4ktest --ioengine=psync --size=4G --bs=4k
4ktest: (g=0): rw=randrw, bs=(R) 4096B-4096B, (W) 4096B-4096B, (T) 4096B-4096B, ioengine=psync, iodepth=128
...
fio-3.28
Starting 12 processes
4ktest: Laying out IO file (1 file / 4096MiB)
Jobs: 12 (f=12): [r(12)][100.0%][r=393MiB/s][r=101k IOPS][eta 00m:00s]
4ktest: (groupid=0, jobs=12): err= 0: pid=8181: Wed Jan 18 18:23:29 2023
read: IOPS=101k, BW=393MiB/s (412MB/s)(23.0GiB/60002msec)
clat (nsec): min=1142, max=2033.2k, avg=115234.72, stdev=54456.22
lat (nsec): min=1173, max=2033.4k, avg=115657.83, stdev=54512.98
clat percentiles (usec):
| 1.00th=[ 7], 5.00th=[ 11], 10.00th=[ 16], 20.00th=[ 92],
| 30.00th=[ 101], 40.00th=[ 110], 50.00th=[ 123], 60.00th=[ 137],
| 70.00th=[ 147], 80.00th=[ 155], 90.00th=[ 165], 95.00th=[ 174],
| 99.00th=[ 208], 99.50th=[ 269], 99.90th=[ 510], 99.95th=[ 578],
| 99.99th=[ 840]
bw ( KiB/s): min=319881, max=561475, per=100.00%, avg=403066.91, stdev=5629.87, samples=1416
iops : min=79965, max=140366, avg=100762.93, stdev=1407.46, samples=1416
lat (usec) : 2=0.01%, 4=0.06%, 10=4.01%, 20=8.58%, 50=2.20%
lat (usec) : 100=14.05%, 250=70.50%, 500=0.49%, 750=0.09%, 1000=0.02%
lat (msec) : 2=0.01%, 4=0.01%
cpu : usr=4.26%, sys=95.71%, ctx=15540, majf=0, minf=0
IO depths : 1=100.0%, 2=0.0%, 4=0.0%, 8=0.0%, 16=0.0%, 32=0.0%, >=64=0.0%
submit : 0=0.0%, 4=100.0%, 8=0.0%, 16=0.0%, 32=0.0%, 64=0.0%, >=64=0.0%
complete : 0=0.0%, 4=100.0%, 8=0.0%, 16=0.0%, 32=0.0%, 64=0.0%, >=64=0.0%
issued rwts: total=6040028,0,0,0 short=0,0,0,0 dropped=0,0,0,0
latency : target=0, window=0, percentile=100.00%, depth=128
Run status group 0 (all jobs):
READ: bw=393MiB/s (412MB/s), 393MiB/s-393MiB/s (412MB/s-412MB/s), io=23.0GiB (24.7GB), run=60002-60002msec
Reads
Code:
fio --filename=test --direct=1 --rw=randread --randrepeat=0 --rwmixread=100 --iodepth=128 --numjobs=12 --runtime=60 --group_reporting --name=4ktest --ioengine=psync --size=4G --bs=4k
4ktest: (g=0): rw=randread, bs=(R) 4096B-4096B, (W) 4096B-4096B, (T) 4096B-4096B, ioengine=psync, iodepth=128
...
fio-3.28
Starting 12 processes
Jobs: 12 (f=12): [r(12)][100.0%][r=394MiB/s][r=101k IOPS][eta 00m:00s]
4ktest: (groupid=0, jobs=12): err= 0: pid=8203: Wed Jan 18 18:24:39 2023
read: IOPS=101k, BW=393MiB/s (412MB/s)(23.0GiB/60001msec)
clat (nsec): min=1192, max=2055.0k, avg=115388.32, stdev=55384.50
lat (nsec): min=1242, max=2055.7k, avg=115786.01, stdev=55442.73
clat percentiles (usec):
| 1.00th=[ 7], 5.00th=[ 11], 10.00th=[ 16], 20.00th=[ 91],
| 30.00th=[ 100], 40.00th=[ 109], 50.00th=[ 122], 60.00th=[ 137],
| 70.00th=[ 149], 80.00th=[ 157], 90.00th=[ 167], 95.00th=[ 176],
| 99.00th=[ 212], 99.50th=[ 273], 99.90th=[ 523], 99.95th=[ 635],
| 99.99th=[ 914]
bw ( KiB/s): min=310696, max=581146, per=100.00%, avg=402954.42, stdev=5978.06, samples=1416
iops : min=77670, max=145283, avg=100734.63, stdev=1494.51, samples=1416
lat (usec) : 2=0.01%, 4=0.06%, 10=4.10%, 20=8.52%, 50=2.18%
lat (usec) : 100=15.06%, 250=69.46%, 500=0.50%, 750=0.09%, 1000=0.02%
lat (msec) : 2=0.01%, 4=0.01%
cpu : usr=4.09%, sys=95.88%, ctx=14638, majf=0, minf=12
IO depths : 1=100.0%, 2=0.0%, 4=0.0%, 8=0.0%, 16=0.0%, 32=0.0%, >=64=0.0%
submit : 0=0.0%, 4=100.0%, 8=0.0%, 16=0.0%, 32=0.0%, 64=0.0%, >=64=0.0%
complete : 0=0.0%, 4=100.0%, 8=0.0%, 16=0.0%, 32=0.0%, 64=0.0%, >=64=0.0%
issued rwts: total=6038347,0,0,0 short=0,0,0,0 dropped=0,0,0,0
latency : target=0, window=0, percentile=100.00%, depth=128
Run status group 0 (all jobs):
READ: bw=393MiB/s (412MB/s), 393MiB/s-393MiB/s (412MB/s-412MB/s), io=23.0GiB (24.7GB), run=60001-60001msec
