Error Codes - Need Help

R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
I am getting the following message in my FreeNAS Core 13

Pool Tank state is ONLINE: One or more devices has experienced an error resulting in data corruption. Applications may be affected.​

2022-07-19 12:53:22 (America/Boise)

I am able to read and right the media folder that has been stored on the shared drives, but am having trouble with plex also.
The main issue is how to figure out the pool tank message above.
As a noob, I am just not sure how to figure this out. Any help would be appreciated. Thanks, Bob Ivey

Samuel Tai

Samuel Tai

Never underestimate your own stupidity
Moderator
Joined
Apr 24, 2020
Messages
5,399
Please provide the output of zpool status -v Tank. This will tell you which specific disks in your pool are faulty, and which specific files and/or metadata are corrupted.

E

elvisimprsntr

Guru
Joined
Jun 2, 2019
Messages
591
post the output of the following commands

Code:
zpool status -v
zpool list -v
find /dev/ada* -exec smartctl -a {} \;

R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
As requested, these are the three screenshots as requested
Code:
root@truenas[~]# zpool status -v Tank

  pool: Tank
 state: ONLINE
status: One or more devices has experienced an error resulting in data
        corruption.  Applications may be affected.
action: Restore the file in question if possible.  Otherwise restore the
        entire pool from backup.
   see: https://openzfs.github.io/openzfs-docs/msg/ZFS-8000-8A
  scan: resilvered 10.3G in 00:03:00 with 0 errors on Tue Jul 19 12:52:57 2022
config:

        NAME                                            STATE     READ WRITE CKSUM
        Tank                                            ONLINE       0     0     0
          raidz2-0                                      ONLINE       0     0     0
            gptid/e4cbdbac-edf4-11ec-b757-3cecef470cb8  ONLINE       0     0     0
            gptid/e4ca0372-edf4-11ec-b757-3cecef470cb8  ONLINE       0     0     0
            gptid/e4b2c82d-edf4-11ec-b757-3cecef470cb8  ONLINE       0     0     0
            gptid/e4ccc633-edf4-11ec-b757-3cecef470cb8  ONLINE       0     0     0
            gptid/e4cae25e-edf4-11ec-b757-3cecef470cb8  ONLINE       0     0     0
          raidz2-1                                      ONLINE       0     0     0
            gptid/74d8b7b9-edf5-11ec-b757-3cecef470cb8  ONLINE       0     0     0
            gptid/74de68d5-edf5-11ec-b757-3cecef470cb8  ONLINE       0     0     0
            gptid/74dd958c-edf5-11ec-b757-3cecef470cb8  ONLINE       0     0     0
            gptid/74dcc44e-edf5-11ec-b757-3cecef470cb8  ONLINE       0



Code:
root@truenas[~]# zpool list -v
NAME                                             SIZE  ALLOC   FREE  CKPOINT EXPANDSZ FRAG   CAP  DEDUP    HEALTH  ALTROOT
Tank                                            81.8T  13.5T  68.3T        -     -     0%    16%  1.00x    ONLINE  /mnt
  raidz2-0                                      45.5T  7.52T  37.9T        -     -     0%  16.5%      -    ONLINE
    gptid/e4cbdbac-edf4-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/e4ca0372-edf4-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/e4b2c82d-edf4-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/e4ccc633-edf4-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/e4cae25e-edf4-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
  raidz2-1                                      36.4T  5.97T  30.4T        -     -     0%  16.4%      -    ONLINE
    gptid/74d8b7b9-edf5-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/74de68d5-edf5-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/74dd958c-edf5-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/74dcc44e-edf5-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE
    gptid/74d48aac-edf5-11ec-b757-3cecef470cb8      -      -      -        -     -      -      -      -    ONLINE




Warning: the supported mechanisms for making configuration changes
are the TrueNAS WebUI and API exclusively. ALL OTHERS ARE
NOT SUPPORTED AND WILL RESULT IN UNDEFINED BEHAVIOR AND MAY
RESULT IN SYSTEM FAILURE.

root@truenas[~]# find /dev/ada* -exec smartctl -a {} \;
smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: WD Blue / Red / Green SSDs
Device Model: WDC WDS250G2B0A-00SM50
Serial Number: 212010800239
LU WWN Device Id: 5 001b44 8bae193a6
Firmware Version: 401020WD
User Capacity: 250,059,350,016 bytes [250 GB]
Sector Size: 512 bytes logical/physical
Rotation Rate: Solid State Device
Form Factor: 2.5 inches
TRIM Command: Available, deterministic, zeroed
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-4 T13/BSR INCITS 529 revision 5
SATA Version is: SATA 3.3, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:01:38 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x00) Offline data collection activity
was never started.
Auto Offline Data Collection: Disabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 0) seconds.
Offline data collection
capabilities: (0x11) SMART execute Offline immediate.
No Auto Offline data collection support.
Suspend Offline collection upon new
command.
No Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
No Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: ( 10) minutes.

SMART Attributes Data Structure revision number: 4
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
5 Reallocated_Sector_Ct 0x0032 100 100 --- Old_age Always - 0
9 Power_On_Hours 0x0032 100 100 --- Old_age Always - 8274
12 Power_Cycle_Count 0x0032 100 100 --- Old_age Always - 69
165 Block_Erase_Count 0x0032 100 100 --- Old_age Always - 458756
166 Minimum_PE_Cycles_TLC 0x0032 100 100 --- Old_age Always - 0
167 Max_Bad_Blocks_per_Die 0x0032 100 100 --- Old_age Always - 11
168 Maximum_PE_Cycles_TLC 0x0032 100 100 --- Old_age Always - 1
169 Total_Bad_Blocks 0x0032 100 100 --- Old_age Always - 47
170 Grown_Bad_Blocks 0x0032 100 100 --- Old_age Always - 0
171 Program_Fail_Count 0x0032 100 100 --- Old_age Always - 0
172 Erase_Fail_Count 0x0032 100 100 --- Old_age Always - 0
173 Average_PE_Cycles_TLC 0x0032 100 100 --- Old_age Always - 0
174 Unexpected_Power_Loss 0x0032 100 100 --- Old_age Always - 51
184 End-to-End_Error 0x0032 100 100 --- Old_age Always - 0
187 Reported_Uncorrect 0x0032 100 100 --- Old_age Always - 0
188 Command_Timeout 0x0032 100 100 --- Old_age Always - 0
194 Temperature_Celsius 0x0022 065 048 --- Old_age Always - 35 (Min/Max 25/48)
199 UDMA_CRC_Error_Count 0x0032 100 100 --- Old_age Always - 0
230 Media_Wearout_Indicator 0x0032 001 001 --- Old_age Always - 0x000000000000
232 Available_Reservd_Space 0x0033 100 100 004 Pre-fail Always - 100
233 NAND_GB_Written_TLC 0x0032 100 100 --- Old_age Always - 11
234 NAND_GB_Written_SLC 0x0032 100 100 --- Old_age Always - 24
241 Host_Writes_GiB 0x0030 253 253 --- Old_age Offline - 22
242 Host_Reads_GiB 0x0030 253 253 --- Old_age Offline - 178
244 Temp_Throttle_Status 0x0032 000 100 --- Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 8251 -

Selective Self-tests/Logging not supported

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/ada0p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/ada0p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/ada0p3: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: WD Blue / Red / Green SSDs
Device Model: WDC WDS250G2B0A-00SM50
Serial Number: 212010800137
LU WWN Device Id: 5 001b44 8bae193ed
Firmware Version: 401020WD
User Capacity: 250,059,350,016 bytes [250 GB]
Sector Size: 512 bytes logical/physical
Rotation Rate: Solid State Device
Form Factor: 2.5 inches
TRIM Command: Available, deterministic, zeroed
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-4 T13/BSR INCITS 529 revision 5
SATA Version is: SATA 3.3, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:01:38 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x00) Offline data collection activity
was never started.
Auto Offline Data Collection: Disabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 0) seconds.
Offline data collection
capabilities: (0x11) SMART execute Offline immediate.
No Auto Offline data collection support.
Suspend Offline collection upon new
command.
No Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
No Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: ( 10) minutes.

SMART Attributes Data Structure revision number: 4
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
5 Reallocated_Sector_Ct 0x0032 100 100 --- Old_age Always - 0
9 Power_On_Hours 0x0032 100 100 --- Old_age Always - 8274
12 Power_Cycle_Count 0x0032 100 100 --- Old_age Always - 69
165 Block_Erase_Count 0x0032 100 100 --- Old_age Always - 458756
166 Minimum_PE_Cycles_TLC 0x0032 100 100 --- Old_age Always - 0
167 Max_Bad_Blocks_per_Die 0x0032 100 100 --- Old_age Always - 17
168 Maximum_PE_Cycles_TLC 0x0032 100 100 --- Old_age Always - 1
169 Total_Bad_Blocks 0x0032 100 100 --- Old_age Always - 79
170 Grown_Bad_Blocks 0x0032 100 100 --- Old_age Always - 0
171 Program_Fail_Count 0x0032 100 100 --- Old_age Always - 0
172 Erase_Fail_Count 0x0032 100 100 --- Old_age Always - 0
173 Average_PE_Cycles_TLC 0x0032 100 100 --- Old_age Always - 0
174 Unexpected_Power_Loss 0x0032 100 100 --- Old_age Always - 53
184 End-to-End_Error 0x0032 100 100 --- Old_age Always - 0
187 Reported_Uncorrect 0x0032 100 100 --- Old_age Always - 0
188 Command_Timeout 0x0032 100 100 --- Old_age Always - 0
194 Temperature_Celsius 0x0022 065 048 --- Old_age Always - 35 (Min/Max 25/48)
199 UDMA_CRC_Error_Count 0x0032 100 100 --- Old_age Always - 0
230 Media_Wearout_Indicator 0x0032 001 001 --- Old_age Always - 0x000000000000
232 Available_Reservd_Space 0x0033 100 100 004 Pre-fail Always - 100
233 NAND_GB_Written_TLC 0x0032 100 100 --- Old_age Always - 12
234 NAND_GB_Written_SLC 0x0032 100 100 --- Old_age Always - 24
241 Host_Writes_GiB 0x0030 253 253 --- Old_age Offline - 22
242 Host_Reads_GiB 0x0030 253 253 --- Old_age Offline - 165
244 Temp_Throttle_Status 0x0032 000 100 --- Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 8251 -

Selective Self-tests/Logging not supported

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/ada1p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/ada1p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-2
Click to expand...

Samuel Tai

Samuel Tai

Never underestimate your own stupidity
Moderator
Joined
Apr 24, 2020
Messages
5,399
Sorry, your zpool status -v Tank was truncated. Also, @elvisimprsntr didn't pick up you're running on HBAs. We actually need find /dev/da[0-9] -exec smartctl -a {} \; and smartctl -a /dev/da10.

Last edited:
R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
Samuel Tai said:
Sorry, your zpool status -v Tank was truncated. Also, @elvisimprsntr didn't pick up you're running on HBAs. We actually need find /dev/da* -exec smartctl -a {} \;.
Click to expand...

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da2p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da2p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: Western Digital Ultrastar He10/12
Device Model: WDC WD80EMAZ-00WJTA0
Serial Number: 7SGYV4AC
LU WWN Device Id: 5 000cca 252cd90e3
Firmware Version: 83.H0A83
User Capacity: 8,001,563,222,016 bytes [8.00 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5400 rpm
Form Factor: 3.5 inches
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ATA8-ACS T13/1699-D revision 4
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:34:03 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x80) Offline data collection activity
was never started.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 93) seconds.
Offline data collection
capabilities: (0x5b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: (1025) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000b 100 100 016 Pre-fail Always - 0
2 Throughput_Performance 0x0004 128 128 054 Old_age Offline - 116
3 Spin_Up_Time 0x0007 203 203 024 Pre-fail Always - 232 (Average 417)
4 Start_Stop_Count 0x0012 100 100 000 Old_age Always - 311
5 Reallocated_Sector_Ct 0x0033 100 100 005 Pre-fail Always - 0
7 Seek_Error_Rate 0x000a 100 100 067 Old_age Always - 0
8 Seek_Time_Performance 0x0004 128 128 020 Old_age Offline - 18
9 Power_On_Hours 0x0012 096 096 000 Old_age Always - 33943
10 Spin_Retry_Count 0x0012 100 100 060 Old_age Always - 0
12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 311
22 Helium_Level 0x0023 100 100 025 Pre-fail Always - 100
192 Power-Off_Retract_Count 0x0032 099 099 000 Old_age Always - 1718
193 Load_Cycle_Count 0x0012 099 099 000 Old_age Always - 1718
194 Temperature_Celsius 0x0002 154 154 000 Old_age Always - 42 (Min/Max 19/53)
196 Reallocated_Event_Count 0x0032 100 100 000 Old_age Always - 0
197 Current_Pending_Sector 0x0022 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0008 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x000a 200 200 000 Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 33919 -

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da3p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da3p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: Western Digital Red
Device Model: WDC WD80EFAX-68LHPN0
Serial Number: 7SGJGH6C
LU WWN Device Id: 5 000cca 252c77c55
Firmware Version: 83.H0A83
User Capacity: 8,001,563,222,016 bytes [8.00 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5400 rpm
Form Factor: 3.5 inches
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ATA8-ACS T13/1699-D revision 4
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:34:03 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x80) Offline data collection activity
was never started.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 93) seconds.
Offline data collection
capabilities: (0x5b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: (1037) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000b 100 100 016 Pre-fail Always - 0
2 Throughput_Performance 0x0004 129 129 054 Old_age Offline - 112
3 Spin_Up_Time 0x0007 173 173 024 Pre-fail Always - 354 (Average 408)
4 Start_Stop_Count 0x0012 100 100 000 Old_age Always - 457
5 Reallocated_Sector_Ct 0x0033 100 100 005 Pre-fail Always - 0
7 Seek_Error_Rate 0x000a 100 100 067 Old_age Always - 0
8 Seek_Time_Performance 0x0004 128 128 020 Old_age Offline - 18
9 Power_On_Hours 0x0012 096 096 000 Old_age Always - 32846
10 Spin_Retry_Count 0x0012 100 100 060 Old_age Always - 0
12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 451
22 Helium_Level 0x0023 100 100 025 Pre-fail Always - 100
192 Power-Off_Retract_Count 0x0032 099 099 000 Old_age Always - 1784
193 Load_Cycle_Count 0x0012 099 099 000 Old_age Always - 1784
194 Temperature_Celsius 0x0002 162 162 000 Old_age Always - 40 (Min/Max 19/54)
196 Reallocated_Event_Count 0x0032 100 100 000 Old_age Always - 0
197 Current_Pending_Sector 0x0022 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0008 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x000a 200 200 000 Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 32822 -
# 2 Short offline Interrupted (host reset) 10% 1712 -
# 3 Extended offline Completed without error 00% 1360 -
# 4 Short offline Completed without error 00% 1343 -
# 5 Short offline Completed without error 00% 1157 -
# 6 Short offline Completed without error 00% 413 -
# 7 Extended offline Completed without error 00% 18 -
# 8 Short offline Completed without error 00% 2 -

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da4p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da4p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: Western Digital Ultrastar He10/12
Device Model: WDC WD100EMAZ-00WJTA0
Serial Number: JEGKTV4N
LU WWN Device Id: 5 000cca 267c81791
Firmware Version: 83.H0A83
User Capacity: 10,000,831,348,736 bytes [10.0 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5400 rpm
Form Factor: 3.5 inches
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ATA8-ACS T13/1699-D revision 4
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:34:03 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x80) Offline data collection activity
was never started.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 93) seconds.
Offline data collection
capabilities: (0x5b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: (1140) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000b 100 100 016 Pre-fail Always - 0
2 Throughput_Performance 0x0004 129 129 054 Old_age Offline - 112
3 Spin_Up_Time 0x0007 176 176 024 Pre-fail Always - 410 (Average 338)
4 Start_Stop_Count 0x0012 100 100 000 Old_age Always - 204
5 Reallocated_Sector_Ct 0x0033 100 100 005 Pre-fail Always - 0
7 Seek_Error_Rate 0x000a 100 100 067 Old_age Always - 0
8 Seek_Time_Performance 0x0004 128 128 020 Old_age Offline - 18
9 Power_On_Hours 0x0012 097 097 000 Old_age Always - 27424
10 Spin_Retry_Count 0x0012 100 100 060 Old_age Always - 0
12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 204
22 Helium_Level 0x0023 100 100 025 Pre-fail Always - 100
192 Power-Off_Retract_Count 0x0032 099 099 000 Old_age Always - 1340
193 Load_Cycle_Count 0x0012 099 099 000 Old_age Always - 1340
194 Temperature_Celsius 0x0002 166 166 000 Old_age Always - 39 (Min/Max 19/54)
196 Reallocated_Event_Count 0x0032 100 100 000 Old_age Always - 0
197 Current_Pending_Sector 0x0022 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0008 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x000a 200 200 000 Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 27401 -

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da5p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da5p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: Western Digital Ultrastar He10/12
Device Model: WDC WD100EMAZ-00WJTA0
Serial Number: JEGKVHZN
LU WWN Device Id: 5 000cca 267c81dd8
Firmware Version: 83.H0A83
User Capacity: 10,000,831,348,736 bytes [10.0 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5400 rpm
Form Factor: 3.5 inches
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ATA8-ACS T13/1699-D revision 4
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:34:03 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x80) Offline data collection activity
was never started.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 93) seconds.
Offline data collection
capabilities: (0x5b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: (1080) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000b 100 100 016 Pre-fail Always - 0
2 Throughput_Performance 0x0004 130 130 054 Old_age Offline - 108
3 Spin_Up_Time 0x0007 200 200 024 Pre-fail Always - 200 (Average 459)
4 Start_Stop_Count 0x0012 100 100 000 Old_age Always - 208
5 Reallocated_Sector_Ct 0x0033 100 100 005 Pre-fail Always - 0
7 Seek_Error_Rate 0x000a 100 100 067 Old_age Always - 0
8 Seek_Time_Performance 0x0004 128 128 020 Old_age Offline - 18
9 Power_On_Hours 0x0012 097 097 000 Old_age Always - 27424
10 Spin_Retry_Count 0x0012 100 100 060 Old_age Always - 0
12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 208
22 Helium_Level 0x0023 100 100 025 Pre-fail Always - 100
192 Power-Off_Retract_Count 0x0032 099 099 000 Old_age Always - 1408
193 Load_Cycle_Count 0x0012 099 099 000 Old_age Always - 1408
194 Temperature_Celsius 0x0002 151 151 000 Old_age Always - 43 (Min/Max 19/55)
196 Reallocated_Event_Count 0x0032 100 100 000 Old_age Always - 0
197 Current_Pending_Sector 0x0022 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0008 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x000a 200 200 000 Old_age Always - 0


Next Post will have the second half. Won't let my post be more than 3000 characters.
Click to expand...

R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
This is the second half of the previous post.
Click to expand...

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 27401 -

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da6p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da6p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: Western Digital Ultrastar He10/12
Device Model: WDC WD100EMAZ-00WJTA0
Serial Number: JEGJU8JN
LU WWN Device Id: 5 000cca 267c7a4d1
Firmware Version: 83.H0A83
User Capacity: 10,000,831,348,736 bytes [10.0 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5400 rpm
Form Factor: 3.5 inches
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ATA8-ACS T13/1699-D revision 4
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:34:04 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x82) Offline data collection activity
was completed without error.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 93) seconds.
Offline data collection
capabilities: (0x5b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: (1208) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000b 100 100 016 Pre-fail Always - 0
2 Throughput_Performance 0x0004 128 128 054 Old_age Offline - 116
3 Spin_Up_Time 0x0007 253 253 024 Pre-fail Always - 237 (Average 256)
4 Start_Stop_Count 0x0012 100 100 000 Old_age Always - 211
5 Reallocated_Sector_Ct 0x0033 100 100 005 Pre-fail Always - 0
7 Seek_Error_Rate 0x000a 100 100 067 Old_age Always - 0
8 Seek_Time_Performance 0x0004 128 128 020 Old_age Offline - 18
9 Power_On_Hours 0x0012 096 096 000 Old_age Always - 28494
10 Spin_Retry_Count 0x0012 100 100 060 Old_age Always - 0
12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 211
22 Helium_Level 0x0023 100 100 025 Pre-fail Always - 100
192 Power-Off_Retract_Count 0x0032 099 099 000 Old_age Always - 1463
193 Load_Cycle_Count 0x0012 099 099 000 Old_age Always - 1463
194 Temperature_Celsius 0x0002 151 151 000 Old_age Always - 43 (Min/Max 19/55)
196 Reallocated_Event_Count 0x0032 100 100 000 Old_age Always - 0
197 Current_Pending_Sector 0x0022 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0008 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x000a 200 200 000 Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 28471 -

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da7p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da7p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: Western Digital Ultrastar He10/12
Device Model: WDC WD100EMAZ-00WJTA0
Serial Number: 2TK1AJ1D
LU WWN Device Id: 5 000cca 26aeae25d
Firmware Version: 83.H0A83
User Capacity: 10,000,831,348,736 bytes [10.0 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5400 rpm
Form Factor: 3.5 inches
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ATA8-ACS T13/1699-D revision 4
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:34:04 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x80) Offline data collection activity
was never started.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 93) seconds.
Offline data collection
capabilities: (0x5b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: (1061) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000b 100 100 016 Pre-fail Always - 0
2 Throughput_Performance 0x0004 130 130 054 Old_age Offline - 108
3 Spin_Up_Time 0x0007 253 253 024 Pre-fail Always - 198 (Average 266)
4 Start_Stop_Count 0x0012 100 100 000 Old_age Always - 216
5 Reallocated_Sector_Ct 0x0033 100 100 005 Pre-fail Always - 0
7 Seek_Error_Rate 0x000a 100 100 067 Old_age Always - 0
8 Seek_Time_Performance 0x0004 128 128 020 Old_age Offline - 18
9 Power_On_Hours 0x0012 096 096 000 Old_age Always - 28755
10 Spin_Retry_Count 0x0012 100 100 060 Old_age Always - 0
12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 216
22 Helium_Level 0x0023 100 100 025 Pre-fail Always - 100
192 Power-Off_Retract_Count 0x0032 099 099 000 Old_age Always - 1461
193 Load_Cycle_Count 0x0012 099 099 000 Old_age Always - 1461
194 Temperature_Celsius 0x0002 151 151 000 Old_age Always - 43 (Min/Max 18/55)
196 Reallocated_Event_Count 0x0032 100 100 000 Old_age Always - 0
197 Current_Pending_Sector 0x0022 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0008 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x000a 200 200 000 Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 28755 -
# 2 Short offline Completed without error 00% 28754 -
# 3 Extended offline Interrupted (host reset) 70% 28753 -
# 4 Short offline Completed without error 00% 28749 -
# 5 Short offline Completed without error 00% 28748 -
# 6 Short offline Completed without error 00% 28747 -
# 7 Short offline Completed without error 00% 28746 -
# 8 Short offline Completed without error 00% 28745 -
# 9 Short offline Completed without error 00% 28744 -
#10 Short offline Completed without error 00% 28743 -
#11 Short offline Completed without error 00% 28742 -
#12 Short offline Completed without error 00% 28741 -
#13 Short offline Completed without error 00% 28740 -
#14 Short offline Completed without error 00% 28739 -
#15 Short offline Completed without error 00% 28738 -
#16 Short offline Completed without error 00% 28737 -
#17 Short offline Completed without error 00% 28736 -
#18 Short offline Completed without error 00% 28735 -
#19 Short offline Completed without error 00% 28734 -
#20 Short offline Completed without error 00% 28733 -
#21 Short offline Completed without error 00% 28732 -

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da8p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da8p2: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family: Western Digital Ultrastar He10/12
Device Model: WDC WD100EMAZ-00WJTA0
Serial Number: JEGU8LVN
LU WWN Device Id: 5 000cca 267cb7d97
Firmware Version: 83.H0A83
User Capacity: 10,000,831,348,736 bytes [10.0 TB]
Sector Sizes: 512 bytes logical, 4096 bytes physical
Rotation Rate: 5400 rpm
Form Factor: 3.5 inches
Device is: In smartctl database [for details use: -P show]
ATA Version is: ACS-2, ATA8-ACS T13/1699-D revision 4
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Tue Jul 19 17:34:04 2022 MDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status: (0x80) Offline data collection activity
was never started.
Auto Offline Data Collection: Enabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 93) seconds.
Offline data collection
capabilities: (0x5b) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: (1037) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE
1 Raw_Read_Error_Rate 0x000b 100 100 016 Pre-fail Always - 0
2 Throughput_Performance 0x0004 131 131 054 Old_age Offline - 104
3 Spin_Up_Time 0x0007 243 243 024 Pre-fail Always - 182 (Average 359)
4 Start_Stop_Count 0x0012 100 100 000 Old_age Always - 398
5 Reallocated_Sector_Ct 0x0033 100 100 005 Pre-fail Always - 0
7 Seek_Error_Rate 0x000a 100 100 067 Old_age Always - 0
8 Seek_Time_Performance 0x0004 128 128 020 Old_age Offline - 18
9 Power_On_Hours 0x0012 096 096 000 Old_age Always - 29024
10 Spin_Retry_Count 0x0012 100 100 060 Old_age Always - 0
12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 222
22 Helium_Level 0x0023 100 100 025 Pre-fail Always - 100
192 Power-Off_Retract_Count 0x0032 099 099 000 Old_age Always - 2336
193 Load_Cycle_Count 0x0012 099 099 000 Old_age Always - 2336
194 Temperature_Celsius 0x0002 158 158 000 Old_age Always - 41 (Min/Max 19/53)
196 Reallocated_Event_Count 0x0032 100 100 000 Old_age Always - 0
197 Current_Pending_Sector 0x0022 100 100 000 Old_age Always - 0
198 Offline_Uncorrectable 0x0008 100 100 000 Old_age Offline - 0
199 UDMA_CRC_Error_Count 0x000a 200 200 000 Old_age Always - 0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 29024 -
# 2 Short offline Completed without error 00% 29024 -
# 3 Short offline Completed without error 00% 29023 -
# 4 Short offline Completed without error 00% 29022 -
# 5 Short offline Completed without error 00% 29021 -
# 6 Short offline Completed without error 00% 29020 -
# 7 Short offline Completed without error 00% 29019 -
# 8 Short offline Completed without error 00% 29018 -
# 9 Short offline Completed without error 00% 29017 -
#10 Short offline Completed without error 00% 29016 -
#11 Short offline Completed without error 00% 29015 -
#12 Short offline Completed without error 00% 29014 -
#13 Short offline Completed without error 00% 29013 -
#14 Short offline Completed without error 00% 29012 -
#15 Short offline Completed without error 00% 29011 -
#16 Short offline Completed without error 00% 29010 -
#17 Short offline Completed without error 00% 29009 -
#18 Short offline Completed without error 00% 29008 -
#19 Short offline Completed without error 00% 29007 -
#20 Short offline Completed without error 00% 29006 -
#21 Short offline Completed without error 00% 29005 -

SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-20, Bruce Allen, Christian Franke, www.smartmontools.org

/dev/da9p1: Unable to detect device type
Please specify device type with the -d option.

Use smartctl -h to get a usage summary

smartctl 7.2 2021-09-14 r5236 [FreeBSD 13.1-RELEASE amd64] (local build)
Copyright (C) 2002-2
Click to expand...

Samuel Tai

Samuel Tai

Never underestimate your own stupidity
Moderator
Joined
Apr 24, 2020
Messages
5,399
Please redo zpool status -v Tank.

R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
Took some doing but here it is complete.

root@truenas[~]# zpool status -v Tank
pool: Tank
state: ONLINE
status: One or more devices has experienced an error resulting in data
corruption. Applications may be affected.
action: Restore the file in question if possible. Otherwise restore the
entire pool from backup.
see: https://openzfs.github.io/openzfs-docs/msg/ZFS-8000-8A
scan: resilvered 10.3G in 00:03:00 with 0 errors on Tue Jul 19 12:52:57 2022
config:

NAME STATE READ WRITE CKSUM
Tank ONLINE 0 0 0
raidz2-0 ONLINE 0 0 0
gptid/e4cbdbac-edf4-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/e4ca0372-edf4-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/e4b2c82d-edf4-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/e4ccc633-edf4-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/e4cae25e-edf4-11ec-b757-3cecef470cb8 ONLINE 0 0 0
raidz2-1 ONLINE 0 0 0
gptid/74d8b7b9-edf5-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/74de68d5-edf5-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/74dd958c-edf5-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/74dcc44e-edf5-11ec-b757-3cecef470cb8 ONLINE 0 0 0
gptid/74d48aac-edf5-11ec-b757-3cecef470cb8 ONLINE 0 0 0

errors: Permanent errors have been detected in the following files:

<0x3f7>:<0x25927>
Click to expand...

Samuel Tai

Samuel Tai

Never underestimate your own stupidity
Moderator
Joined
Apr 24, 2020
Messages
5,399
rivey said:
errors: Permanent errors have been detected in the following files:

<0x3f7>:<0x25927>
Click to expand...

This is pool metadata that's corrupt, possibly a single block. Unfortunately, this usually isn't fixable with a scrub. The only sure way of fixing this is to destroy the pool, recreate it, and reload the data.

R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
The interesting part is that I am still able to access all of the media (movies, music, and other video's) and it is still all playing well. I access it via the network share. What would be the best way to test all of the drives on this server. I have plenty of time since I am retired.
An interesting thing is that the trouble that is showing now is data yet last week in was showing the following,

These images from a few days ago are not showing now.
Samuel Tai said:
This is pool metadata that's corrupt, possibly a single block. Unfortunately, this usually isn't fixable with a scrub. The only sure way of fixing this is to destroy the pool, recreate it, and reload the data.
Click to expand...





E

elvisimprsntr

Guru
Joined
Jun 2, 2019
Messages
591
Have you run an extended (long) self test on the suspect drives?

Code:
geom disk list # Name is the disk device name, descr is the disk model number, indent is the disk serial number
smartctl -t long /dev/daX # X is the drive device name
smartctl -a /dev/daX # to view the progress/status of extended offline test.  can take multiple hours.

R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
elvisimprsntr said:
Have you run an extended (long) self test on the suspect drives?

Code:
geom disk list # Name is the disk device name, descr is the disk model number, indent is the disk serial number
smartctl -t long /dev/daX # X is the drive device name
smartctl -a /dev/daX # to view the progress/status of extended offline test.  can take multiple hours.
Click to expand...

I haven't run the long seft tests but I am going to today. Thanks for the input.

R

rivey

Contributor
Joined
Sep 20, 2017
Messages
123
As an update, I have run smartctl short tests on all drives in "Tank" and all have completed with no errors. I have now started long smart test on all "Tank" drives and they say that they will complete some time tomorrow.
Scrubs will also be scheduled when the long tests are complete.
If all of the long smart tests come back with no errors, I have 2 10TB drive (brand new) that I am thinking of copying all data to as a backup and see what happens.

You must log in or register to reply here.

Important Announcement for the TrueNAS Community.

The TrueNAS Community has now been moved. This forum will now become READ-ONLY for historical purposes. Please feel free to join us on the new TrueNAS Community Forums.

Related topics on forums.truenas.com for thread: "Error Codes - Need Help"

Similar threads

R
Brand New WD Red Drives Showing As Faulted
Replies
2
Views
1K
Samuel Tai
Samuel Tai
M
Pool degraded status after drive replacement
Replies
9
Views
1K
matic443875
M
simos.sigma
How can I get rid of this data corruption message?
Replies
6
Views
1K
Arwen
Arwen
B
  • Locked
Which device has experienced an error?
Replies
13
Views
2K
Bostjan
B
D
error pool
Replies
8
Views
749
dio123
D
Top
