Windows 10 VM Blue Screen MULTIPROCESSOR_CONFIGURATION_NOT_SUPPORTED

[jstockley2020]

Recently I tried to create a windows 10 vm on FreeNAS-11.3-U3.2. After booting to the virtual cd drive I get a blue screen error saying "MULTIPROCESSOR_CONFIGURATION_NOT_SUPPORTED". I have 2 ubuntu vms working perfectly fine. I have even tried to turn them off to see if that would resolve the problem with no luck. My CPU is a AMD FX(tm)-4100 Quad-Core Processor with 24GB of ram. I also have 2 3tb drives with an ssd for caching. If you need any additional information please let me know.

Thanks
Jack



[Patrick M. Hausen]

How many cores have you assigned to your Windows VM?
Set the loader tunable hw.vmm.topology.cores_per_package to at least that number so your VM will see only a single package.

You need to rebbot your FreeNAS for the setting to become effective.



[Samuel Tai]

Try setting these loader tunables to reflect your CPU:

Code:

hw.vmm.topology.cores_per_package=4
hw.vmm.topology.threads_per_core=2

These take effect on reboot.



[jstockley2020]

Try setting these loader tunables to reflect your CPU:

Code:

hw.vmm.topology.cores_per_package=4
hw.vmm.topology.threads_per_core=2

These take effect on reboot.

Awesome that seems to have fixed it thanks guys so much!
