Started having some problems about 5 months ago with a drive but was to busy / lazy to deal with it until I noticed 2 LED's on my HDD bays were off and only flashed red instead of soild blue, 1 drive I know has problems but I can't seem to hunt down the other drive in FreeNAS atm (unless the bay is just being stupid).
Drive da2 started having S.M.A.R.T. errors, I didn't think to much of it at the time but after finally getting around to running a long self test (I still haven't setup auto tests, I know stupid) it's coming back with "2 Currently unreadable (pending) sectors" & "Self-Test Log error count increased from 4 to 5". I've got 2 spare drives ready to go in if I have to replace it so that's not a problem.
So what do you think does it need to be replaced?
Quick question on S.M.A.R.T. tests can I run long tests on all the drives at once? same question about short tests.
Thanks :).
Drive da2 started having S.M.A.R.T. errors, I didn't think to much of it at the time but after finally getting around to running a long self test (I still haven't setup auto tests, I know stupid) it's coming back with "2 Currently unreadable (pending) sectors" & "Self-Test Log error count increased from 4 to 5". I've got 2 spare drives ready to go in if I have to replace it so that's not a problem.
So what do you think does it need to be replaced?
Code:
=== START OF INFORMATION SECTION === Model Family: Western Digital Red Device Model: WDC WD40EFRX-68WT0N0 Serial Number: nope :) LU WWN Device Id: 5 0014ee 2b72346c6 Firmware Version: 82.00A82 User Capacity: 4,000,787,030,016 bytes [4.00 TB] Sector Sizes: 512 bytes logical, 4096 bytes physical Rotation Rate: 5400 rpm Device is: In smartctl database [for details use: -P show] ATA Version is: ACS-2 (minor revision not indicated) SATA Version is: SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s) Local Time is: Sun Jul 16 09:11:26 2017 AEST SMART support is: Available - device has SMART capability. SMART support is: Enabled === START OF READ SMART DATA SECTION === SMART overall-health self-assessment test result: PASSED General SMART Values: Offline data collection status: (0x00) Offline data collection activity was never started. Auto Offline Data Collection: Disabled. Self-test execution status: ( 121) The previous self-test completed having the read element of the test failed. Total time to complete Offline data collection: (51840) seconds. Offline data collection capabilities: (0x7b) SMART execute Offline immediate. Auto Offline data collection on/off support. Suspend Offline collection upon new command. Offline surface scan supported. Self-test supported. Conveyance Self-test supported. Selective Self-test supported. SMART capabilities: (0x0003) Saves SMART data before entering power-saving mode. Supports SMART auto save timer. Error logging capability: (0x01) Error logging supported. General Purpose Logging supported. Short self-test routine recommended polling time: ( 2) minutes. Extended self-test routine recommended polling time: ( 518) minutes. Conveyance self-test routine recommended polling time: ( 5) minutes. SCT capabilities: (0x703d) SCT Status supported. SCT Error Recovery Control supported. SCT Feature Control supported. SCT Data Table supported. SMART Attributes Data Structure revision number: 16 Vendor Specific SMART Attributes with Thresholds: ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE 1 Raw_Read_Error_Rate 0x002f 200 200 051 Pre-fail Always - 248 3 Spin_Up_Time 0x0027 182 181 021 Pre-fail Always - 7900 4 Start_Stop_Count 0x0032 100 100 000 Old_age Always - 28 5 Reallocated_Sector_Ct 0x0033 200 200 140 Pre-fail Always - 0 7 Seek_Error_Rate 0x002e 100 253 000 Old_age Always - 0 9 Power_On_Hours 0x0032 083 083 000 Old_age Always - 12498 10 Spin_Retry_Count 0x0032 100 253 000 Old_age Always - 0 11 Calibration_Retry_Count 0x0032 100 253 000 Old_age Always - 0 12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 28 192 Power-Off_Retract_Count 0x0032 200 200 000 Old_age Always - 26 193 Load_Cycle_Count 0x0032 200 200 000 Old_age Always - 70 194 Temperature_Celsius 0x0022 116 106 000 Old_age Always - 36 196 Reallocated_Event_Count 0x0032 200 200 000 Old_age Always - 0 197 Current_Pending_Sector 0x0032 200 200 000 Old_age Always - 0 198 Offline_Uncorrectable 0x0030 100 253 000 Old_age Offline - 0 199 UDMA_CRC_Error_Count 0x0032 200 200 000 Old_age Always - 0 200 Multi_Zone_Error_Rate 0x0008 100 253 000 Old_age Offline - 0 SMART Error Log Version: 1 No Errors Logged SMART Self-test log structure revision number 1 Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error # 1 Extended offline Completed: read failure 90% 12475 10837785 # 2 Short offline Completed: read failure 30% 11185 10834384 # 3 Short offline Completed: read failure 20% 10898 10837712 # 4 Short offline Completed: read failure 30% 10777 10834648 # 5 Short offline Completed: read failure 30% 10732 10834648 # 6 Short offline Completed without error 00% 2434 - # 7 Short offline Completed without error 00% 2411 - # 8 Short offline Completed without error 00% 2387 - # 9 Short offline Completed without error 00% 2363 - #10 Short offline Completed without error 00% 2339 - #11 Short offline Completed without error 00% 2315 - #12 Short offline Completed without error 00% 2291 - #13 Short offline Completed without error 00% 2267 - #14 Short offline Completed without error 00% 2243 - #15 Short offline Completed without error 00% 2219 - #16 Short offline Completed without error 00% 2195 - #17 Short offline Completed without error 00% 2171 - #18 Short offline Completed without error 00% 2147 - #19 Short offline Completed without error 00% 2123 - #20 Short offline Completed without error 00% 2099 - #21 Short offline Completed without error 00% 2075 - SMART Selective self-test log data structure revision number 1 SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS 1 0 0 Not_testing 2 0 0 Not_testing 3 0 0 Not_testing 4 0 0 Not_testing 5 0 0 Not_testing Selective self-test flags (0x0): After scanning selected spans, do NOT read-scan remainder of disk. If Selective self-test is pending on power-up, resume after 0 minute delay.
Quick question on S.M.A.R.T. tests can I run long tests on all the drives at once? same question about short tests.
Thanks :).
