I want to use native k8s CronJob to implement the DDNS task, below is my YAML, but there is always a problem, someone help me see what the problem is?
k3s version v1.23.5+k3s-fbfa51e5-dirty (fbfa51e5)
go version go1.17.8
os version TrueNAS-SCALE-22.02.2.1
k3s kubectl describe cronjob.batch/cloudflare-updater
k3s kubectl create job --from=cronjob/cloudflare-updater cloudflare-updater
k3s kubectl get all
k3s kubectl describe pod/cloudflare-updater-wdcrs
Maybe it could be a problem with K3S? Can someone try this task on their own server to be successful?
k3s version v1.23.5+k3s-fbfa51e5-dirty (fbfa51e5)
go version go1.17.8
os version TrueNAS-SCALE-22.02.2.1
Code:
# configmap.yaml --- apiVersion: v1 kind: ConfigMap metadata: name: cloudflare-updater namespace: default data: cloudflare-updater.sh: | #!/usr/bin/env bash set -o nounset set -o errexit current_ipv4="$(curl -s https://ipv4.icanhazip.com/)" zone_id=$(curl -s -X GET \ "https://api.cloudflare.com/client/v4/zones?name=${DOMAIN#*.}&status=active" \ -H "Authorization: Bearer $TOKEN" \ -H "Content-Type: application/json" \ | jq --raw-output ".result[0] | .id" ) record_ipv4=$(curl -s -X GET \ "https://api.cloudflare.com/client/v4/zones/${zone_id}/dns_records?name=${DOMAIN}&type=A" \ -H "Authorization: Bearer $TOKEN" \ -H "Content-Type: application/json" \ ) old_ip4=$(echo "$record_ipv4" | jq --raw-output '.result[0] | .content') if [[ "${current_ipv4}" == "${old_ip4}" ]]; then printf "%s - IP Address '%s' has not changed" "$(date -u)" "${current_ipv4}" exit 0 fi record_ipv4_identifier="$(echo "$record_ipv4" | jq --raw-output '.result[0] | .id')" update_ipv4=$(curl -s -X PUT \ "https://api.cloudflare.com/client/v4/zones/${zone_id}/dns_records/${record_ipv4_identifier}" \ -H "Authorization: Bearer $TOKEN" \ -H "Content-Type: application/json" \ --data "{\"id\":\"${zone_id}\",\"type\":\"A\",\"proxied\":false,\"name\":\"${DOMAIN}\",\"content\":\"${current_ipv4}\"}" \ ) if [[ "$(echo "$update_ipv4" | jq --raw-output '.success')" == "true" ]]; then printf "%s - Success - IP Address '%s' has been updated" "$(date -u)" "${current_ipv4}" exit 0 else printf "%s - Yikes - Updating IP Address '%s' has failed" "$(date -u)" "${current_ipv4}" exit 1 fi # secret.yaml --- apiVersion: v1 kind: Secret metadata: name: cloudflare-token namespace: default type: Opaque data: # Your domain name in base64 DOMAIN: fWataR3= # You API token in base64 # Get token from https://dash.cloudflare.com/profile/api-tokens TOKEN: fWataR3= # cronjob.yaml --- apiVersion: batch/v1 kind: CronJob metadata: name: cloudflare-updater namespace: default spec: # At every hours. schedule: "0 * * * *" failedJobsHistoryLimit: 5 successfulJobsHistoryLimit: 3 concurrencyPolicy: Forbid jobTemplate: spec: backoffLimit: 3 ttlSecondsAfterFinished: 300 template: spec: restartPolicy: Never containers: - name: cloudflare-updater image: ghcr.io/k8s-at-home/kubectl:v1.23.5 imagePullPolicy: IfNotPresent envFrom: - secretRef: name: cloudflare-token command: - "/bin/sh" - "-c" - "/app/cloudflare-updater.sh" volumeMounts: - name: cloudflare-updater mountPath: /app/cloudflare-updater.sh subPath: cloudflare-updater.sh readOnly: true volumes: - name: cloudflare-updater projected: defaultMode: 0755 sources: - configMap: name: cloudflare-updater items: - key: cloudflare-updater.sh path: cloudflare-updater.sh
k3s kubectl describe cronjob.batch/cloudflare-updater
Code:
Name: cloudflare-updater Namespace: default Labels: <none> Annotations: <none> Schedule: 0 * * * * Concurrency Policy: Forbid Suspend: False Successful Job History Limit: 3 Failed Job History Limit: 5 Starting Deadline Seconds: <unset> Selector: <unset> Parallelism: <unset> Completions: <unset> Pod Template: Labels: <none> Containers: cloudflare-updater: Image: ghcr.io/k8s-at-home/kubectl:v1.23.5 Port: <none> Host Port: <none> Command: /bin/sh -c /app/cloudflare-updater.sh Environment Variables from: cloudflare-token Secret Optional: false Environment: <none> Mounts: /app/cloudflare-updater.sh from cloudflare-updater (ro,path="cloudflare-updater.sh") Volumes: cloudflare-updater: Type: Projected (a volume that contains injected data from multiple sources) ConfigMapName: cloudflare-updater ConfigMapOptional: <nil> Last Schedule Time: Sun, 10 Jul 2022 21:00:00 +0800 Active Jobs: <none> Events: Type Reason Age From Message ---- ------ ---- ---- ------- Normal SuccessfulCreate 27m cronjob-controller Created job cloudflare-updater-27624300 Normal SawCompletedJob 27m cronjob-controller Saw completed job: cloudflare-updater-27624300, status: Failed
k3s kubectl create job --from=cronjob/cloudflare-updater cloudflare-updater
k3s kubectl get all
Code:
pod/cloudflare-updater-ng4rv 0/1 Error 0 35s pod/cloudflare-updater-jzdt9 0/1 Error 0 31s pod/cloudflare-updater-dc6qf 0/1 Error 0 28s pod/cloudflare-updater-wdcrs 0/1 Error 0 24s
k3s kubectl describe pod/cloudflare-updater-wdcrs
Code:
Name: cloudflare-updater-wdcrs Namespace: default Priority: 0 Node: ix-truenas/10.0.0.10 Start Time: Sun, 10 Jul 2022 21:30:03 +0800 Labels: controller-uid=dac2fa2a-eee7-4fa8-b380-1fc16d8334df job-name=cloudflare-updater Annotations: k8s.v1.cni.cncf.io/network-status: [{ "name": "ix-net", "interface": "eth0", "ips": [ "172.16.1.169" ], "mac": "8a:29:b1:56:1a:6a", "default": true, "dns": {} }] k8s.v1.cni.cncf.io/networks-status: [{ "name": "ix-net", "interface": "eth0", "ips": [ "172.16.1.169" ], "mac": "8a:29:b1:56:1a:6a", "default": true, "dns": {} }] Status: Failed IP: 172.16.1.169 IPs: IP: 172.16.1.169 Controlled By: Job/cloudflare-updater Containers: cloudflare-updater: Container ID: docker://b194a0dafc0684d0ade8b4852c06c2ee5142a4b87b72c0671e2821b8b147aa97 Image: ghcr.io/k8s-at-home/kubectl:v1.23.5 Image ID: docker-pullable://ghcr.io/k8s-at-home/kubectl@sha256:53b37dbf69bc9edf6b43f4f95049b85e233f7055d8e220ef030a337ef9d93dc0 Port: <none> Host Port: <none> Command: /bin/sh -c /app/cloudflare-updater.sh State: Terminated Reason: Error Exit Code: 3 Started: Sun, 10 Jul 2022 21:30:05 +0800 Finished: Sun, 10 Jul 2022 21:30:06 +0800 Ready: False Restart Count: 0 Environment Variables from: cloudflare-token Secret Optional: false Environment: <none> Mounts: /app/cloudflare-updater.sh from cloudflare-updater (ro,path="cloudflare-updater.sh") /var/run/secrets/kubernetes.io/serviceaccount from kube-api-access-vls8j (ro) Conditions: Type Status Initialized True Ready False ContainersReady False PodScheduled True Volumes: cloudflare-updater: Type: Projected (a volume that contains injected data from multiple sources) ConfigMapName: cloudflare-updater ConfigMapOptional: <nil> kube-api-access-vls8j: Type: Projected (a volume that contains injected data from multiple sources) TokenExpirationSeconds: 3607 ConfigMapName: kube-root-ca.crt ConfigMapOptional: <nil> DownwardAPI: true QoS Class: BestEffort Node-Selectors: <none> Tolerations: node.kubernetes.io/not-ready:NoExecute op=Exists for 300s node.kubernetes.io/unreachable:NoExecute op=Exists for 300s Events: Type Reason Age From Message ---- ------ ---- ---- ------- Normal Scheduled 66s default-scheduler Successfully assigned default/cloudflare-updater-wdcrs to ix-truenas Normal AddedInterface 66s multus Add eth0 [172.16.1.169/16] from ix-net Normal Pulled 66s kubelet Container image "ghcr.io/k8s-at-home/kubectl:v1.23.5" already present on machine Normal Created 65s kubelet Created container cloudflare-updater Normal Started 65s kubelet Started container cloudflare-updater Warning FailedMount 62s (x3 over 63s) kubelet MountVolume.SetUp failed for volume "cloudflare-updater" : object "default"/"cloudflare-updater" not registered
Maybe it could be a problem with K3S? Can someone try this task on their own server to be successful?
