SOLVED Slight fear that a drive is failing.... Help?

[sesipod]

Hello all I have a bit of what seems to be a growing issue.

Last week I logged into the FreeNAS UI to find my Z2 ( 9x 3TB ) array in a degraded state. I quickly started to hunt down the drive causing the issue. When I found the drive I simply removed the drive and put it back in the server. Thinking that It might be a loose connection since I just got done moving the server into a new spot. FreeNAS seemed to be happy and returned to a Normal state for about 4 days now until about 30min ago when I logged in and noticed this message.

I am wondering is there any logs that I can have a peak at to see what drive/s (besides the obvious one) that might be causing the issue?

I run smart tests on all of the drives - Long Self-Test every 7 Days and a Short every 12 HRS.


Here is the current Pool Status page:
https://cdn.sesipod.info/images/freenas/123.PNG

I have also attached each drives latest smart test. They all seem to be okay. I'm really stuck here.

Please see below posts for ( CODE BLOCK ) smart data.

Thanks,
sesipod



[ethereal]

i was going to have a look and help but i need to download 9 files - it will be easier for everybody if you put the smart data for each drive between code marks



[sesipod]

i was going to have a look and help but i need to download 9 files - it will be easier for everybody if you put the smart data for each drive between code marks

Spent the last 20+ min editing this post on my iPad remotely. Just to hit the 30,000 character limit trying to post the code blocks.

Here you go.

DA0

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WCC4N3YP92D1
LU WWN Device Id: 5 0014ee 20be12c18
Firmware Version: 82.00A82
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 3.0 Gb/s)
Local Time is:    Sat Jun  8 02:14:39 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x00)    Offline data collection activity
                    was never started.
                    Auto Offline Data Collection: Disabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (41760) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 418) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   180   177   021    Pre-fail  Always       -       5958
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       168
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   053   053   000    Old_age   Always       -       34855
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       141
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       136
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       4337
194 Temperature_Celsius     0x0022   117   107   000    Old_age   Always       -       33
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     34854         -
# 2  Short offline       Completed without error       00%     34853         -
# 3  Short offline       Completed without error       00%     34841         -
# 4  Short offline       Completed without error       00%     34829         -
# 5  Short offline       Completed without error       00%     34817         -
# 6  Short offline       Completed without error       00%     34805         -
# 7  Short offline       Completed without error       00%     34793         -
# 8  Short offline       Completed without error       00%     34781         -
# 9  Short offline       Completed without error       00%     34769         -
#10  Short offline       Completed without error       00%     34757         -
#11  Short offline       Completed without error       00%     34746         -
#12  Short offline       Completed without error       00%     34734         -
#13  Short offline       Completed without error       00%     34722         -
#14  Short offline       Completed without error       00%     34710         -
#15  Short offline       Completed without error       00%     34698         -
#16  Short offline       Completed without error       00%     34686         -
#17  Short offline       Completed without error       00%     34674         -
#18  Short offline       Completed without error       00%     34662         -
#19  Short offline       Completed without error       00%     34650         -
#20  Short offline       Completed without error       00%     34638         -
#21  Short offline       Completed without error       00%     34626         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

DA1

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WMC4N0E8HNZ9
LU WWN Device Id: 5 0014ee 0593cc1a9
Firmware Version: 82.00A82
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:14:58 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x00)    Offline data collection activity
                    was never started.
                    Auto Offline Data Collection: Disabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (41940) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 420) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   182   179   021    Pre-fail  Always       -       5883
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       201
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   047   047   000    Old_age   Always       -       39236
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       174
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       168
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       4913
194 Temperature_Celsius     0x0022   116   107   000    Old_age   Always       -       34
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     39235         -
# 2  Short offline       Completed without error       00%     39234         -
# 3  Short offline       Completed without error       00%     39222         -
# 4  Short offline       Completed without error       00%     39210         -
# 5  Short offline       Completed without error       00%     39198         -
# 6  Short offline       Completed without error       00%     39186         -
# 7  Short offline       Completed without error       00%     39174         -
# 8  Short offline       Completed without error       00%     39162         -
# 9  Short offline       Completed without error       00%     39150         -
#10  Short offline       Completed without error       00%     39138         -
#11  Short offline       Completed without error       00%     39126         -
#12  Short offline       Completed without error       00%     39114         -
#13  Short offline       Completed without error       00%     39102         -
#14  Short offline       Completed without error       00%     39090         -
#15  Short offline       Completed without error       00%     39078         -
#16  Short offline       Completed without error       00%     39066         -
#17  Short offline       Completed without error       00%     39054         -
#18  Short offline       Completed without error       00%     39042         -
#19  Short offline       Completed without error       00%     39030         -
#20  Short offline       Completed without error       00%     39018         -
#21  Short offline       Completed without error       00%     39006         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

DA2

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WMC4N0J0DLLD
LU WWN Device Id: 5 0014ee 6059e0d8e
Firmware Version: 82.00A82
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:14:28 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x00)    Offline data collection activity
                    was never started.
                    Auto Offline Data Collection: Disabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (39900) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 400) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   182   178   021    Pre-fail  Always       -       5875
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       139
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   058   058   000    Old_age   Always       -       31206
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       115
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       110
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       5465
194 Temperature_Celsius     0x0022   115   106   000    Old_age   Always       -       35
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     31205         -
# 2  Short offline       Completed without error       00%     31204         -
# 3  Short offline       Completed without error       00%     31192         -
# 4  Short offline       Completed without error       00%     31180         -
# 5  Short offline       Completed without error       00%     31168         -
# 6  Short offline       Completed without error       00%     31156         -
# 7  Short offline       Completed without error       00%     31144         -
# 8  Short offline       Completed without error       00%     31132         -
# 9  Short offline       Completed without error       00%     31120         -
#10  Short offline       Completed without error       00%     31108         -
#11  Short offline       Completed without error       00%     31096         -
#12  Short offline       Completed without error       00%     31084         -
#13  Short offline       Completed without error       00%     31072         -
#14  Short offline       Completed without error       00%     31060         -
#15  Short offline       Completed without error       00%     31048         -
#16  Short offline       Completed without error       00%     31036         -
#17  Short offline       Completed without error       00%     31024         -
#18  Short offline       Completed without error       00%     31012         -
#19  Short offline       Completed without error       00%     31000         -
#20  Short offline       Completed without error       00%     30988         -
#21  Short offline       Completed without error       00%     30976         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

DA3

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WCC4N1CZPZ74
LU WWN Device Id: 5 0014ee 261365d04
Firmware Version: 82.00A82
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:14:50 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x00)    Offline data collection activity
                    was never started.
                    Auto Offline Data Collection: Disabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (39120) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 393) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   180   175   021    Pre-fail  Always       -       5975
  4 Start_Stop_Count        0x0032   099   099   000    Old_age   Always       -       1210
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   059   059   000    Old_age   Always       -       30071
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       141
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       135
193 Load_Cycle_Count        0x0032   196   196   000    Old_age   Always       -       12028
194 Temperature_Celsius     0x0022   114   106   000    Old_age   Always       -       36
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     30070         -
# 2  Short offline       Completed without error       00%     30069         -
# 3  Short offline       Completed without error       00%     30057         -
# 4  Short offline       Completed without error       00%     30045         -
# 5  Short offline       Completed without error       00%     30033         -
# 6  Short offline       Completed without error       00%     30021         -
# 7  Short offline       Completed without error       00%     30009         -
# 8  Short offline       Completed without error       00%     29997         -
# 9  Short offline       Completed without error       00%     29985         -
#10  Short offline       Completed without error       00%     29973         -
#11  Short offline       Completed without error       00%     29961         -
#12  Short offline       Completed without error       00%     29949         -
#13  Short offline       Completed without error       00%     29937         -
#14  Short offline       Completed without error       00%     29925         -
#15  Short offline       Completed without error       00%     29913         -
#16  Short offline       Completed without error       00%     29901         -
#17  Short offline       Completed without error       00%     29890         -
#18  Short offline       Completed without error       00%     29878         -
#19  Short offline       Completed without error       00%     29866         -
#20  Short offline       Completed without error       00%     29854         -
#21  Short offline       Completed without error       00%     29842         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.



[sesipod]

DA4

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WCC4N7SCA908
LU WWN Device Id: 5 0014ee 2b73df32a
Firmware Version: 82.00A82
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:14:18 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x00)    Offline data collection activity
                    was never started.
                    Auto Offline Data Collection: Disabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (40320) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 404) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   223   175   021    Pre-fail  Always       -       3825
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       139
  5 Reallocated_Sector_Ct   0x0033   197   197   140    Pre-fail  Always       -       100
  7 Seek_Error_Rate         0x002e   196   195   000    Old_age   Always       -       289
  9 Power_On_Hours          0x0032   059   059   000    Old_age   Always       -       30338
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       115
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       110
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       4224
194 Temperature_Celsius     0x0022   116   107   000    Old_age   Always       -       34
196 Reallocated_Event_Count 0x0032   173   173   000    Old_age   Always       -       27
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     30337         -
# 2  Short offline       Completed without error       00%     30336         -
# 3  Short offline       Completed without error       00%     30324         -
# 4  Short offline       Completed without error       00%     30312         -
# 5  Short offline       Completed without error       00%     30300         -
# 6  Short offline       Completed without error       00%     30288         -
# 7  Short offline       Completed without error       00%     30276         -
# 8  Short offline       Completed without error       00%     30264         -
# 9  Short offline       Completed without error       00%     30252         -
#10  Short offline       Completed without error       00%     30240         -
#11  Short offline       Completed without error       00%     30049         -
#12  Short offline       Completed without error       00%     30037         -
#13  Short offline       Completed without error       00%     30023         -
#14  Short offline       Completed without error       00%     30011         -
#15  Short offline       Completed without error       00%     29999         -
#16  Short offline       Completed without error       00%     29987         -
#17  Short offline       Completed without error       00%     29975         -
#18  Short offline       Completed without error       00%     29963         -
#19  Short offline       Completed without error       00%     29951         -
#20  Short offline       Completed without error       00%     29939         -
#21  Short offline       Completed without error       00%     29927         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

DA5

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WCC4N6JZKEHP
LU WWN Device Id: 5 0014ee 261e81120
Firmware Version: 82.00A82
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:14:08 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x00)    Offline data collection activity
                    was never started.
                    Auto Offline Data Collection: Disabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (39720) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 399) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   177   174   021    Pre-fail  Always       -       6133
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       138
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   059   059   000    Old_age   Always       -       30338
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       114
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       109
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       4496
194 Temperature_Celsius     0x0022   115   107   000    Old_age   Always       -       35
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     30337         -
# 2  Short offline       Completed without error       00%     30336         -
# 3  Short offline       Completed without error       00%     30324         -
# 4  Short offline       Completed without error       00%     30312         -
# 5  Short offline       Completed without error       00%     30300         -
# 6  Short offline       Completed without error       00%     30288         -
# 7  Short offline       Completed without error       00%     30276         -
# 8  Short offline       Completed without error       00%     30264         -
# 9  Short offline       Completed without error       00%     30252         -
#10  Short offline       Completed without error       00%     30240         -
#11  Short offline       Completed without error       00%     30228         -
#12  Short offline       Completed without error       00%     30216         -
#13  Short offline       Completed without error       00%     30204         -
#14  Short offline       Completed without error       00%     30192         -
#15  Short offline       Completed without error       00%     30180         -
#16  Short offline       Completed without error       00%     30168         -
#17  Short offline       Completed without error       00%     30156         -
#18  Short offline       Completed without error       00%     30144         -
#19  Short offline       Completed without error       00%     30132         -
#20  Short offline       Completed without error       00%     30120         -
#21  Short offline       Completed without error       00%     30108         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

DA6

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WMC4N2276055
LU WWN Device Id: 5 0014ee 604478841
Firmware Version: 80.00A80
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:15:20 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x85)    Offline data collection activity
                    was aborted by an interrupting command from host.
                    Auto Offline Data Collection: Enabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (40500) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 406) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   181   177   021    Pre-fail  Always       -       5950
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       228
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   041   041   000    Old_age   Always       -       43521
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       200
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       193
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       4285
194 Temperature_Celsius     0x0022   115   106   000    Old_age   Always       -       35
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   200   200   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   200   200   000    Old_age   Offline      -       0

SMART Error Log Version: 1
ATA Error Count: 10 (device log contains only the most recent five errors)
    CR = Command Register [HEX]
    FR = Features Register [HEX]
    SC = Sector Count Register [HEX]
    SN = Sector Number Register [HEX]
    CL = Cylinder Low Register [HEX]
    CH = Cylinder High Register [HEX]
    DH = Device/Head Register [HEX]
    DC = Device Command Register [HEX]
    ER = Error register [HEX]
    ST = Status register [HEX]
Powered_Up_Time is measured from power on, and printed as
DDd+hh:mm:SS.sss where DD=days, hh=hours, mm=minutes,
SS=sec, and sss=millisec. It "wraps" after 49.710 days.

Error 10 occurred at disk power-on lifetime: 2469 hours (102 days + 21 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08   6d+01:59:30.555  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08   6d+01:59:30.555  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08   6d+01:59:30.555  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:30.554  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:30.553  SMART WRITE LOG

Error 9 occurred at disk power-on lifetime: 2469 hours (102 days + 21 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08   6d+01:59:30.555  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08   6d+01:59:30.555  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:30.554  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:30.553  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:30.552  SMART WRITE LOG

Error 8 occurred at disk power-on lifetime: 2157 hours (89 days + 21 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08      00:57:43.540  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08      00:57:43.539  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08      00:57:43.539  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08      00:57:43.538  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08      00:57:43.538  SMART READ LOG

Error 7 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:10:15.306  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:10:15.306  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:10:15.305  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:10:15.304  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:10:15.304  SMART READ LOG

Error 6 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:09:43.472  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:09:43.472  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:09:43.471  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:09:43.470  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:09:43.470  SMART READ LOG

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     43520         -
# 2  Short offline       Completed without error       00%     43519         -
# 3  Short offline       Completed without error       00%     43507         -
# 4  Short offline       Completed without error       00%     43495         -
# 5  Short offline       Completed without error       00%     43483         -
# 6  Short offline       Completed without error       00%     43471         -
# 7  Short offline       Completed without error       00%     43459         -
# 8  Short offline       Completed without error       00%     43447         -
# 9  Short offline       Completed without error       00%     43435         -
#10  Short offline       Completed without error       00%     43423         -
#11  Short offline       Completed without error       00%     43411         -
#12  Short offline       Completed without error       00%     43399         -
#13  Short offline       Completed without error       00%     43387         -
#14  Short offline       Completed without error       00%     43375         -
#15  Short offline       Completed without error       00%     43363         -
#16  Short offline       Completed without error       00%     43351         -
#17  Short offline       Completed without error       00%     43339         -
#18  Short offline       Completed without error       00%     43327         -
#19  Short offline       Completed without error       00%     43315         -
#20  Short offline       Completed without error       00%     43303         -
#21  Short offline       Completed without error       00%     43291         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.



[sesipod]

DA7

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WMC4N2084563
LU WWN Device Id: 5 0014ee 6aef3efbe
Firmware Version: 80.00A80
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:15:08 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x85)    Offline data collection activity
                    was aborted by an interrupting command from host.
                    Auto Offline Data Collection: Enabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (40320) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 404) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   181   178   021    Pre-fail  Always       -       5933
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       228
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   041   041   000    Old_age   Always       -       43522
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       200
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       193
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       4289
194 Temperature_Celsius     0x0022   114   106   000    Old_age   Always       -       36
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   200   200   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   200   200   000    Old_age   Offline      -       0

SMART Error Log Version: 1
ATA Error Count: 7 (device log contains only the most recent five errors)
    CR = Command Register [HEX]
    FR = Features Register [HEX]
    SC = Sector Count Register [HEX]
    SN = Sector Number Register [HEX]
    CL = Cylinder Low Register [HEX]
    CH = Cylinder High Register [HEX]
    DH = Device/Head Register [HEX]
    DC = Device Command Register [HEX]
    ER = Error register [HEX]
    ST = Status register [HEX]
Powered_Up_Time is measured from power on, and printed as
DDd+hh:mm:SS.sss where DD=days, hh=hours, mm=minutes,
SS=sec, and sss=millisec. It "wraps" after 49.710 days.

Error 7 occurred at disk power-on lifetime: 2469 hours (102 days + 21 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08   6d+01:59:13.092  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08   6d+01:59:13.092  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:13.091  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:13.090  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08   6d+01:59:13.090  SMART READ LOG

Error 6 occurred at disk power-on lifetime: 2157 hours (89 days + 21 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08      00:57:50.286  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08      00:57:50.286  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08      00:57:50.285  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08      00:57:50.284  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08      00:57:50.284  SMART READ LOG

Error 5 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:10:25.795  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:10:25.795  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:10:25.794  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:10:25.793  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:10:25.793  SMART READ LOG

Error 4 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:09:05.420  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:09:05.420  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:09:05.419  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:09:05.418  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:09:05.418  SMART READ LOG

Error 3 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:04:20.596  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:04:20.596  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:04:20.595  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:04:20.594  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:04:20.594  SMART READ LOG

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     43520         -
# 2  Short offline       Completed without error       00%     43520         -
# 3  Short offline       Completed without error       00%     43508         -
# 4  Short offline       Completed without error       00%     43496         -
# 5  Short offline       Completed without error       00%     43484         -
# 6  Short offline       Completed without error       00%     43472         -
# 7  Short offline       Completed without error       00%     43460         -
# 8  Short offline       Completed without error       00%     43448         -
# 9  Short offline       Completed without error       00%     43436         -
#10  Short offline       Completed without error       00%     43424         -
#11  Short offline       Completed without error       00%     43412         -
#12  Short offline       Completed without error       00%     43400         -
#13  Short offline       Completed without error       00%     43388         -
#14  Short offline       Completed without error       00%     43376         -
#15  Short offline       Completed without error       00%     43364         -
#16  Short offline       Completed without error       00%     43352         -
#17  Short offline       Completed without error       00%     43340         -
#18  Short offline       Completed without error       00%     43328         -
#19  Short offline       Completed without error       00%     43316         -
#20  Short offline       Completed without error       00%     43304         -
#21  Short offline       Completed without error       00%     43292         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.

DA9

Code:

smartctl 6.6 2017-11-05 r4594 [FreeBSD 11.2-STABLE amd64] (local build)
Copyright (C) 2002-17, Bruce Allen, Christian Franke, www.smartmontools.org

=== START OF INFORMATION SECTION ===
Model Family:     Western Digital Red
Device Model:     WDC WD30EFRX-68EUZN0
Serial Number:    WD-WCC4N4RR3TJP
LU WWN Device Id: 5 0014ee 261e9525e
Firmware Version: 82.00A82
User Capacity:    3,000,592,982,016 bytes [3.00 TB]
Sector Sizes:     512 bytes logical, 4096 bytes physical
Rotation Rate:    5400 rpm
Device is:        In smartctl database [for details use: -P show]
ATA Version is:   ACS-2 (minor revision not indicated)
SATA Version is:  SATA 3.0, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is:    Sat Jun  8 02:13:57 2019 PDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled

=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED

General SMART Values:
Offline data collection status:  (0x00)    Offline data collection activity
                    was never started.
                    Auto Offline Data Collection: Disabled.
Self-test execution status:      (   0)    The previous self-test routine completed
                    without error or no self-test has ever
                    been run.
Total time to complete Offline
data collection:         (39720) seconds.
Offline data collection
capabilities:              (0x7b) SMART execute Offline immediate.
                    Auto Offline data collection on/off support.
                    Suspend Offline collection upon new
                    command.
                    Offline surface scan supported.
                    Self-test supported.
                    Conveyance Self-test supported.
                    Selective Self-test supported.
SMART capabilities:            (0x0003)    Saves SMART data before entering
                    power-saving mode.
                    Supports SMART auto save timer.
Error logging capability:        (0x01)    Error logging supported.
                    General Purpose Logging supported.
Short self-test routine
recommended polling time:      (   2) minutes.
Extended self-test routine
recommended polling time:      ( 399) minutes.
Conveyance self-test routine
recommended polling time:      (   5) minutes.
SCT capabilities:            (0x703d)    SCT Status supported.
                    SCT Error Recovery Control supported.
                    SCT Feature Control supported.
                    SCT Data Table supported.

SMART Attributes Data Structure revision number: 16
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME          FLAG     VALUE WORST THRESH TYPE      UPDATED  WHEN_FAILED RAW_VALUE
  1 Raw_Read_Error_Rate     0x002f   200   200   051    Pre-fail  Always       -       0
  3 Spin_Up_Time            0x0027   185   182   021    Pre-fail  Always       -       5750
  4 Start_Stop_Count        0x0032   100   100   000    Old_age   Always       -       132
  5 Reallocated_Sector_Ct   0x0033   200   200   140    Pre-fail  Always       -       0
  7 Seek_Error_Rate         0x002e   200   200   000    Old_age   Always       -       0
  9 Power_On_Hours          0x0032   059   059   000    Old_age   Always       -       30028
10 Spin_Retry_Count        0x0032   100   100   000    Old_age   Always       -       0
11 Calibration_Retry_Count 0x0032   100   100   000    Old_age   Always       -       0
12 Power_Cycle_Count       0x0032   100   100   000    Old_age   Always       -       108
192 Power-Off_Retract_Count 0x0032   200   200   000    Old_age   Always       -       103
193 Load_Cycle_Count        0x0032   199   199   000    Old_age   Always       -       3881
194 Temperature_Celsius     0x0022   118   108   000    Old_age   Always       -       32
196 Reallocated_Event_Count 0x0032   200   200   000    Old_age   Always       -       0
197 Current_Pending_Sector  0x0032   200   200   000    Old_age   Always       -       0
198 Offline_Uncorrectable   0x0030   100   253   000    Old_age   Offline      -       0
199 UDMA_CRC_Error_Count    0x0032   200   200   000    Old_age   Always       -       0
200 Multi_Zone_Error_Rate   0x0008   100   253   000    Old_age   Offline      -       0

SMART Error Log Version: 1
No Errors Logged

SMART Self-test log structure revision number 1
Num  Test_Description    Status                  Remaining  LifeTime(hours)  LBA_of_first_error
# 1  Short offline       Completed without error       00%     30027         -
# 2  Short offline       Completed without error       00%     30026         -
# 3  Short offline       Completed without error       00%     30014         -
# 4  Short offline       Completed without error       00%     30002         -
# 5  Short offline       Completed without error       00%     29990         -
# 6  Short offline       Completed without error       00%     29978         -
# 7  Short offline       Completed without error       00%     29966         -
# 8  Short offline       Completed without error       00%     29954         -
# 9  Short offline       Completed without error       00%     29942         -
#10  Short offline       Completed without error       00%     29930         -
#11  Short offline       Completed without error       00%     29919         -
#12  Short offline       Completed without error       00%     29907         -
#13  Short offline       Completed without error       00%     29895         -
#14  Short offline       Completed without error       00%     29883         -
#15  Short offline       Completed without error       00%     29871         -
#16  Short offline       Completed without error       00%     29859         -
#17  Short offline       Completed without error       00%     29847         -
#18  Short offline       Completed without error       00%     29835         -
#19  Short offline       Completed without error       00%     29823         -
#20  Short offline       Completed without error       00%     29811         -
#21  Short offline       Completed without error       00%     29799         -

SMART Selective self-test log data structure revision number 1
SPAN  MIN_LBA  MAX_LBA  CURRENT_TEST_STATUS
    1        0        0  Not_testing
    2        0        0  Not_testing
    3        0        0  Not_testing
    4        0        0  Not_testing
    5        0        0  Not_testing
Selective self-test flags (0x0):
  After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.



[joeschmuck]

Instead of listing all your drives, next time start off with the suspect drive. DA4 is a problem,
Serial Number: WD-WCC4N7SCA908

ID 5 = 100, very bad as you have hardware failures right now, replace this drive. ID 196 is also bad and odds are those failures will end up being added to ID 5.

Also, I don't see you running any SMART Long tests, you need to do this also, my recommendation is once a week. This would have likely shown your errors much sooner.



[sesipod]

Instead of listing all your drives, next time start off with the suspect drive. DA4 is a problem,
Serial Number: WD-WCC4N7SCA908

ID 5 = 100, very bad as you have hardware failures right now, replace this drive. ID 196 is also bad and odds are those failures will end up being added to ID 5.

Also, I don't see you running any SMART Long tests, you need to do this also, my recommendation is once a week. This would have likely shown your errors much sooner.

--

AH! Okay will remember this for next time! I initially posted them all as attachments so one could pick the one that they wanted to look at :). Not needing to create a mile long thread of posts just for the drives.

Thank you for your time! I will put in an order ASAP for a new drive :)
Since I have the drives listed there should I really be concerned at this time with any of the others ?


--

Having a look at FreeNAS It looks like I have them Setup for every 7 days?



[Jailer]

I would keep an eye on da7 as well. And in my opinion every 12 hours for short smart tests is a bit excessive.



[sesipod]

Does the Log test look to be setup correctly ?

I was told in a previous post months ago that I should do Long 7 day and Short 12 hrs. So what should I change Short to? Every 24 ?

Also can you please let me know what you are looking at to say that I should keep an eye on DA7 for ?



[Jailer]

Also can you please let me know what you are looking at to say that I should keep an eye on DA7 for ?

These:

Code:

Error 7 occurred at disk power-on lifetime: 2469 hours (102 days + 21 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08   6d+01:59:13.092  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08   6d+01:59:13.092  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:13.091  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08   6d+01:59:13.090  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08   6d+01:59:13.090  SMART READ LOG

Error 6 occurred at disk power-on lifetime: 2157 hours (89 days + 21 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08      00:57:50.286  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08      00:57:50.286  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08      00:57:50.285  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08      00:57:50.284  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08      00:57:50.284  SMART READ LOG

Error 5 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:10:25.795  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:10:25.795  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:10:25.794  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:10:25.793  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:10:25.793  SMART READ LOG

Error 4 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:09:05.420  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:09:05.420  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:09:05.419  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:09:05.418  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:09:05.418  SMART READ LOG

Error 3 occurred at disk power-on lifetime: 1306 hours (54 days + 10 hours)
  When the command that caused the error occurred, the device was active or idle.

  After command completion occurred, registers were:
  ER ST SC SN CL CH DH
  -- -- -- -- -- -- --
  04 51 01 00 00 00 00  Error: ABRT

  Commands leading to the command that caused the error were:
  CR FR SC SN CL CH DH DC   Powered_Up_Time  Command/Feature_Name
  -- -- -- -- -- -- -- --  ----------------  --------------------
  b0 d5 01 e1 4f c2 00 08  28d+11:04:20.596  SMART READ LOG
  b0 d5 01 e1 4f c2 00 08  28d+11:04:20.596  SMART READ LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:04:20.595  SMART WRITE LOG
  b0 d6 01 e0 4f c2 00 08  28d+11:04:20.594  SMART WRITE LOG
  b0 d5 01 e0 4f c2 00 08  28d+11:04:20.594  SMART READ LOG

Since they occurred some time ago it may be a non issue but I would watch that drive closely and have a spare ready for it.



[joeschmuck]

Change the Hours to Every 24, or if you can select a specific time that would be fine to, that is for both Short and Long tests. It looks like you are running the short tests twice a day. While that isn't a problem really, but it rolls the SelfTest Log over so we cannot see that a Long Test was completed to pass. I'll bet the DA4 drive doesn't pass right now.

As for DA7 and DA6, I suspect that these are connected to a different I/O card from the other drives (let me know if I'm correct), and the error messages you should keep an eye on but because there are nor other related errors, I don't think the drives are failing yet.



[sesipod]

Change the Hours to Every 24, or if you can select a specific time that would be fine to, that is for both Short and Long tests. It looks like you are running the short tests twice a day. While that isn't a problem really, but it rolls the SelfTest Log over so we cannot see that a Long Test was completed to pass.

Okay so I have switched the Short to every 21 HR every day. The Long tests are now Set to every 23 HR every 6 days. ( So confusing )
Does this look better??

I'll bet the DA4 drive doesn't pass right now.

As for DA7 and DA6, I suspect that these are connected to a different I/O card from the other drives (let me know if I'm correct), and the error messages you should keep an eye on but because there are nor other related errors, I don't think the drives are failing yet.

I have already placed a order for a new drive to replace DA4 with amazon it will be here tomorrow. I can almost guarantee at this point that it will not pass and my data is far to important to fart around with it anymore :P ( I got my 5 years out of the drive. )


I have another post out there about DA6 and DA7 from 2018 and they told me that it was not really anything to bother with at that time. - https://www.ixsystems.com/community...ce-my-2-smart-error-drives.70569/#post-489326


I have a 9211-4i that is connected to a RES2SV240 all of the drives connect to that 24 port expander. So all of the drives are on the same controller card being the 9211-4i.

Ignore the mess of cables in the case- I have not updated these pictures in forever. Most of the cable runs have been fixed to be cleaner.



[Stux]

Drives fail. You run smart tests to detect this sooner rather than later.

You run raidz2 so that you can withstand two simultaneous fails.

When a drive fails you replace it and move on :)

Congrats on exceeding 5 years from all your drives ;)



[ethereal]

make sure the long tests are actually being run on all the drives. i had a problem as not every disc was selected correctly

because of this problem i have a script running once a week and i make sure every disc has a short and long test and that they have all passed



[sesipod]

Congrats on exceeding 5 years from all your drives ;)

Thanks! All of the drives except one expired mid 2017 ( 3 year warranty ) the 9th drive expired mid 2018 this one was a hot spare when I was running Z1 before switching to Z2. - I'd say the very close to 5 years that I got out of them is worth the $90-100 that I payed for them. Only having one drive that has had an issue (DA4) that needs to be replaced so far is amazing in my book!

i have a script running once a week and i make sure every disc has a short and long test

I guess I will run a manual Long check on them. Can I run the long tests concurrent?
Can I login to SSH and just issue the smart command per each drive right after one another?



[Jailer]

Can I login to SSH and just issue the smart command per each drive right after one another?

Yup.



[joeschmuck]

As @ethereal said, it is very easy to have selected all your drives one time and then down the road they all or some become unselected. My experience is it happened to me when I replaced a drive and to prevent this kind of oversight from happening again I created my own pair of scripts to run both a SMART Short Test and SMART Long Test. There are a few scripts on the forums (search the resources) that will run the SMART tests for you and send you an email with the results. Here is an email example of my Daily Status. I run the Short script daily under CRON and the Long script once a week under CRON. The output from my script is actually longer, I include all the raw data output but the first part is the summary which I'm showing below. And I retain my emails in a separate email folder for historical purposes, just in case there is some trend I can see. Not all error messages mean the drive is failing, sometimes it's the data cable or controller.

Code:

Subj: SMART Testing Results - All is Good

########## SMART status report summary for all drives ##########
style='font-size:10.5pt;color:black'>
style='font-size:10.5pt;color:black'>+------+---------------+----+-----+-----+-----+-----+-------+-------+--------+------+------+------+------+------+-------+----+
style='font-size:10.5pt;color:black'>|Device|Serial         |Temp|Power|Power|Start|Spin |ReAlloc|Current|Offline |Multi |Load  |UDMA  |Seek  |High  |Command|Last|
style='font-size:10.5pt;color:black'>|      |               |    |On   |On   |Stop |Retry|Sectors|Pending|Uncorrec|Zone  |Cycle |CRC   |Errors|Fly   |Timeout|Test|
style='font-size:10.5pt;color:black'>|      |               |    |Hours|Years|Count|Count|       |Sectors|Sectors |Errors|Count |Errors|      |Writes|Count  |Age |
style='font-size:10.5pt;color:black'>+------+---------------+----+-----+-----+-----+-----+-------+-------+--------+------+------+------+------+------+-------+----+
style='font-size:10.5pt;color:black'>|ada0  |K1JUMLBD       | 36 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   672|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>|ada1  |K1JRSWLD       | 34 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   671|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>|ada2  |K1JUMW4D       | 34 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   667|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>|ada3  |K1GVD84B       | 34 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   684|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>+------+---------------+----+-----+-----+-----+-----+-------+-------+--------+------+------+------+------+------+-------+----+
style='font-size:10.5pt;color:black'>

You can see that I color the font in my HTML email. If there is something wrong then I turn it RED and BOLD so it stands out, and the Subj: line changes as well.

Hope this helps.



[sesipod]

As @ethereal said, it is very easy to have selected all your drives one time and then down the road they all or some become unselected. My experience is it happened to me when I replaced a drive and to prevent this kind of oversight from happening again I created my own pair of scripts to run both a SMART Short Test and SMART Long Test. There are a few scripts on the forums (search the resources) that will run the SMART tests for you and send you an email with the results. Here is an email example of my Daily Status. I run the Short script daily under CRON and the Long script once a week under CRON. The output from my script is actually longer, I include all the raw data output but the first part is the summary which I'm showing below. And I retain my emails in a separate email folder for historical purposes, just in case there is some trend I can see. Not all error messages mean the drive is failing, sometimes it's the data cable or controller.

Code:

Subj: SMART Testing Results - All is Good

########## SMART status report summary for all drives ##########
style='font-size:10.5pt;color:black'>
style='font-size:10.5pt;color:black'>+------+---------------+----+-----+-----+-----+-----+-------+-------+--------+------+------+------+------+------+-------+----+
style='font-size:10.5pt;color:black'>|Device|Serial         |Temp|Power|Power|Start|Spin |ReAlloc|Current|Offline |Multi |Load  |UDMA  |Seek  |High  |Command|Last|
style='font-size:10.5pt;color:black'>|      |               |    |On   |On   |Stop |Retry|Sectors|Pending|Uncorrec|Zone  |Cycle |CRC   |Errors|Fly   |Timeout|Test|
style='font-size:10.5pt;color:black'>|      |               |    |Hours|Years|Count|Count|       |Sectors|Sectors |Errors|Count |Errors|      |Writes|Count  |Age |
style='font-size:10.5pt;color:black'>+------+---------------+----+-----+-----+-----+-----+-------+-------+--------+------+------+------+------+------+-------+----+
style='font-size:10.5pt;color:black'>|ada0  |K1JUMLBD       | 36 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   672|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>|ada1  |K1JRSWLD       | 34 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   671|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>|ada2  |K1JUMW4D       | 34 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   667|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>|ada3  |K1GVD84B       | 34 |13109|1.496|   35|    0|      0|      0|       0|   N/A|   684|     0|   N/A|   N/A|    N/A|   1|
style='font-size:10.5pt;color:black'>+------+---------------+----+-----+-----+-----+-----+-------+-------+--------+------+------+------+------+------+-------+----+
style='font-size:10.5pt;color:black'>

You can see that I color the font in my HTML email. If there is something wrong then I turn it RED and BOLD so it stands out, and the Subj: line changes as well.

Hope this helps.

This looks amazing! I would love to learn how to set something like this up! :o



[joeschmuck]

This looks amazing! I would love to learn how to set something like this up!

Search the forums, you will find a lot of postings telling you exactly how to do it. And I'd rather not retype a new thread on setting up scripts for monitoring SMART data. I prefer to do a Google search for something like "freenas smart script" and see where that takes you.

Warning: If you have never done a script before, please read the threads in advance. You will run into problems with permissions or privledges and modifying the files to run. It's all documented. If you do get stuck after practicing and making a fair attempt, then ask for some help and be descriptive in what is going wrong. Post your script as well (change your email address in the script for privacy reasons if you desire but do not delete the email address, you could have the format wrong). We will help but my goal here is to teach you about how a script works so that you can modify it to meet your needs. Also you might consider using a simple script to start with. There are some scripts that can be very complicated.

Just to help you out a little here is a thread I started a long time ago, all still holds true today. you will note that there are other versions of scripts as well. There are 7 long pages in this thread, worth reading every message. Things start off simple and get complex. You may end up with the complex version but try to understand what is going on, only because you should know what you are doing, do not take it on blind faith.

https://www.ixsystems.com/community/threads/set-up-smart-reporting-via-email.6211/

Good Luck!



[sesipod]

Wanted to report back and say that I have replaced DA4 on Sunday and the resync completed 5HRS later :) everything is looking good as of the moment. I will work on getting a script together soon for the SMART data. Thanks to everyone that helped out!
