KDB enter panic during the installation

[Dad0634]

Gm, i was installing truenas on a real pc, i've installed it on several vm in the past, but never on a pc, and in worked just fine.
Now, when i launch the installation, it return an error:

KDB: enter: panic
[ thread pid 1 tid 100002 ]
Stopped at kdb_enter+0x37: movq $0,0x141d7fe(%rip)


This on truenas 13 and 12, if i try installing freenas 11, it work just fine

I've tried changing the ram with other stick, but nothing changed

Here my hardware:
asus h61m
i7-3770
10gb ram (1x2gb + 1x8gb)
3x hdd 500gb
1x ssd 240gb
1x 32gb usb drive as boot drive
1x 8gb usb drive for installing the os

what can i try to fix?



[DiWa]

Hi Dad0634,
Did you find any solution or further information somewhere?

I'm facing this exact same issue while upgrading my Truenas 12U8.1 to 13 and even today with 13U1.
While booting just after the 1st Truenas boot menu I have this panic mode

Be it 13.0 or 13U1 I face the exact same log.

Each time I change my env when booting to go back to 12U8.1 and my Truenas starts up without a glitch.
Once up, I remove the 13x boot entry.
I've tried a long test on my boot SSD that didn't report any failure.

Can it be related to NAS-116667 even though I don't use such High-Point RAID,can it be another missing module?

My setup:

• asrock E3C226D2I
• i3-4160 CPU
• 16GB DDR3 ECC
• 6x3TB WD RED
• 1 Transcend 64 Go SATA III 6 Go/s MSA230S mSATA SSD 230S Solid State Drive (BOOT Device)
• 10Gtek® 10GbE PCIE - Intel X520-DA1

Thanks for any idea on how to fix this.



[DiWa]

I think I found the reason for my failure.
My Truenas is enclosed in a wall rack where I installed lately some USB fan to extract hot air.
This USB fan is plugged directly on the NAS mobo to get 5V through USB.
Weirdly enough I just unplugged it and the upgrade went to completion!
I hope this will help future generations (At least my future self for the next upgrade )
