Jail network problem after openvpn server installation

[flywithu]

Hi
I enabled the OpenVpn server on Freenas 12. After I can use openvpn server but from jail's to outside network is not working. (Jail's internal network is possible)
I'm sure but Jail's network seems to also use the natd network. How to set the network for jails?

I can't connect internal network from jail, but can connect internal network from outside jail
###Inside JAIL
root@mqtt:/ # ssh 192.168.10.5
======> Timeout

###Outside JAIL
root@freenas:~ # ssh 192.168.10.5
root@192.168.10.5's password:



Freenas: 192.168.10.100/24
OpenVpn: 192.168.20.0/24

##################################################################
root@freenas:~ # netstat -r
Routing tables

Internet:
Destination Gateway Flags Netif Expire
default 192.168.10.1 UGS bge0
localhost lo0 UHS lo0
192.168.10.0/24 192.168.10.1 UGS bge0
192.168.10.100 link#1 UHS lo0
192.168.20.0/24 192.168.10.100 UGS bge0
192.168.20.1 link#7 UHS lo0
192.168.20.2 link#7 UH tun0

Internet6:
Destination Gateway Flags Netif Expire
::/96 localhost UGRS lo0
localhost lo0 UHS lo0
::ffff:0.0.0.0/96 localhost UGRS lo0
fe80::/10 localhost UGRS lo0
fe80::%lo0/64 link#3 U lo0
fe80::1%lo0 link#3 UHS lo0
ff02::/16 localhost UGRS lo0


###########################################################
From JAIL
root@mqtt:/ # netstat -rn
Routing tables

Internet:
Destination Gateway Flags Netif Expire
default 192.168.10.1 UGS epair0b
127.0.0.1 link#1 UH lo0
192.168.10.0/24 link#3 U epair0b
192.168.10.113 link#3 UHS lo0

Internet6:
Destination Gateway Flags Netif Expire
::/96 ::1 UGRS lo0
::1 link#1 UH lo0
::ffff:0.0.0.0/96 ::1 UGRS lo0
fe80::/10 ::1 UGRS lo0
fe80::%lo0/64 link#1 U lo0
fe80::1%lo0 link#1 UHS lo0
ff02::/16 ::1 UGRS lo0



[Mixel]

Hi, same issues here. Have you been able to resolve this?
