Hello all together,
i want to setup a dedicated NIC for the Kubernetes Node and can not find a useful documentation for that.
That's what i already tried:
NIC 1 -> 10.10.10.250 (also configured as the TrueNAS Web UI ip)
NIC 2 -> 10.10.40.250 (configured as Kubernetes NodeIP)
After installing an app from TrueCharts (Plex) i can ping the IP and can make a port test, but i can not open the Web UI.
Do i missed some settings here, or is there a documentation on setting up that correctly?
Regards,
Sascha Grau
TrueNAS-SCALE-22.02.1
i want to setup a dedicated NIC for the Kubernetes Node and can not find a useful documentation for that.
That's what i already tried:
NIC 1 -> 10.10.10.250 (also configured as the TrueNAS Web UI ip)
NIC 2 -> 10.10.40.250 (configured as Kubernetes NodeIP)
Kubernetes
NodeIP : 10.10.40.250
Route v4 interface: NIC2
Route v4 gateway: 10.10.40.1
After installing an app from TrueCharts (Plex) i can ping the IP and can make a port test, but i can not open the Web UI.
PS C:\> ping 10.10.40.250
Pinging 10.10.40.250 with 32 bytes of data:
Reply from 10.10.40.250: bytes=32 time<1ms TTL=64
...
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 0ms, Average = 0ms
PS C:\> tnc 10.10.40.250 -port 32400
ComputerName : 10.10.40.250
RemoteAddress : 10.10.40.250
RemotePort : 32400
InterfaceAlias : Ethernet
SourceAddress : 10.10.10.203
TcpTestSucceeded : True
Do i missed some settings here, or is there a documentation on setting up that correctly?
Regards,
Sascha Grau
TrueNAS-SCALE-22.02.1
