TrueNAS has built-in virtualization capabilities that allow running multiple operating systems on a single system, maximizing hardware utilization, and consolidating workloads.

A virtual machine (VM) is a software-based computer that runs inside your TrueNAS system, and appears as a separate physical machine to the operating system installed within it. VMs use virtualized hardware components, including, network interfaces, storage volumes, graphics adapters, and other devices, providing complete isolation between different operating systems and applications.

VMs offer stronger isolation than containers but require more system resources, making them ideal for running full operating systems, legacy applications, or services that need dedicated environments.

What system resources do VMs require?

TrueNAS assigns a portion of system RAM and a new zvol to each VM. While a VM is running, these resources are not available to the host computer or other VMs.

Virtualization requires:

x86 machine running a recent Linux kernel
Intel processor with VT (Virtualization Technology) extensions, OR
AMD processor with SVM extensions (AMD-V)

Users cannot create VMs unless the host system supports these features.

Users with multiple GPUs who wish to pass a GPU to a VM must first isolate a GPU for VM use. One GPU is always required by TrueNAS.

Creating a Virtual Machine

Before creating a VM:

Obtain an installer .iso or image file for the OS you intend to install
Create a zvol on a storage pool that is available for both the virtual disk and the OS install file.

If the VM needs to access local NAS storage, you must create a network bridge to allow communication. See Accessing TrueNAS Storage from a VM below for more information.

Using the Create Virtual Machine Wizard

To create a new VM, go to Virtual Machines and click Add to open the Create Virtual Machine wizard. If you have not yet added a virtual machine to your system, clicking Add Virtual Machines opens the same wizard.

Configure the Operating System settings.
a. Select the operating system for the VM from the Guest Operating System dropdown list.
Figure 1: Operating System Settings
Compare the recommended specifications for the guest operating system with your available host system resources when allocating virtual CPUs, cores, threads, and memory size.
b. Enter a name for the VM.
c. (Optional) Enter a description for the VM. This can be any short text string describing how the VM is used or which operating system is configured.
d. (Optional) Change the default settings in System Clock and Boot Method to suit your use case. Select UTC as the VM system time from the System Clock dropdown if you do not want to use the default Local setting. Select UEFI from the Boot Method dropdown, unless using an older OS that requires Legacy BIOS.
e. (Optional) Select Enable Secure Boot to enable cryptographic verification of boot loaders, operating system kernels, and drivers during VM startup. This security feature prevents unauthorized or malicious code from running during the boot process by checking digital signatures against trusted certificates. Secure Boot is required for Windows 11 and some Linux distributions, and can be optional or unsupported for older operating systems. Secure boot is only available from the VM creation wizard.
f. (Optional) Select Enable Trusted Platform Module (TPM) to provide a virtual TPM 2.0 device for the VM. TPM provides hardware-based security functions, including secure key storage, cryptographic operations, and platform attestation. This is required for Windows 11 and enhances security for other operating systems that support TPM.
g. (Optional) Select Start on Boot to start the VM after the system is restarted or boots up.
h. (Optional) Select Enable Display (VNC) to enable a Virtual Network Computing (VNC) remote connection for the VM. Enable Display (VNC) shows the Bind and Password fields.
i. Select the IP address or option to use in Bind. Shows if you select Enable Display. The Bind and Password fields display. If it is selected, to change the default IP address to use a specific address as the display network interface; otherwise, leave it set to 0.0.0.0. The Bind list populates with any existing logical interfaces, such as static routes, configured on the system. You cannot edit the Bind setting after saving the VM settings.
j. Enter a password to secure access to the virtual display in Password. The Password field shows if you select Enable Display. The login screen for the display shows a credential entry field for this password.
Click Next.
Enter the CPU and Memory settings for your VM.
Figure 2: CPU and Memory Settings
When the Guest Operating System is set to Windows, Virtual CPUs shows the default value of 2. The VM operating system might have operational or licensing restrictions on the number of CPUs.
Do not allocate too much memory to a VM. Activating a VM with all available memory allocated to it can slow the host system or prevent other VMs from starting.
Leave CPU Mode set to Custom if you want to select a CPU model.
Use Memory Size and Minimum Memory Size to specify how much RAM to dedicate to this VM. To dedicate a fixed amount of RAM, enter a value (minimum 256 MiB) in the Memory Size field and leave Minimum Memory Size empty.
To allow for memory usage flexibility (sometimes called ballooning), define a specific value in the Minimum Memory Size field and a larger value in Memory Size. The VM uses the Minimum Memory Size for normal operations but can dynamically allocate up to the defined Memory Size value in situations where the VM requires additional memory. Reviewing available memory from within the VM typically shows the Minimum Memory Size.
Click Next.
Configure Disks settings.
Figure 3: Disks Settings
Select Create new disk image to create a new zvol on an existing dataset.
Select Use existing disk image to use an existing zvol for the VM.
Select either AHCI or VirtIO from the Select Disk Type dropdown list. We recommend using AHCI for Windows VMs.
Select the location for the new zvol from the Zvol Location dropdown list.
Enter a value in Size (Examples: 500KiB, 500M, and 2TB) to indicate the amount of space to allocate for the new zvol.
Click Next.
Configure Network Interface settings.
Figure 4: Network Interface Settings
Select the network interface type from the Adapter Type dropdown list. Select Intel e82585 (e1000) as it offers a higher level of compatibility with most operating systems.
Select VirtIO if the guest operating system supports para-virtualized network drivers. The VirtIO network interface requires a guest OS that supports VirtIO para-virtualized network drivers.
Select the network interface card to use from the Attach NIC dropdown list. If the VM needs to access local NAS storage, attach a network bridge interface.
Click Next.
Configure Installation Media settings to upload the operating system you selected in step 1.
Figure 5: Installation Media Settings
You can create the VM without an OS installed, then edit the VM to add it later. To add the installation media, type the path or browse to select the location of the image file, and then select it.
To upload an iso, click Upload New Image File. Enter the path or browse to select the location of the file.
Figure 6: Upload Installation Media
Click Upload to begin the upload process. After the upload finishes, click Next.
Specify GPU settings. When available, use a GPU previously isolated for VM use.
Figure 7: GPU Settings
TrueNAS does not have a list of approved GPUs at this time, but TrueNAS does support various NVIDIA, Intel, and AMD GPUs.
Confirm your VM settings, then click Save.

Adding and Removing Devices

Using the Create Virtual Machine wizard configures at least one disk and NIC, and optionally a CD-ROM and display as part of the process, but you can add more devices to suit your use case. Go to Virtual Machines, then click anywhere on a VM entry to expand it and show the options for the VM.

The VM options change when the VM is running.

Click Devices to open the Devices screen for that VM. Click the more_vert icon at the right of each listed device to see device options.

The devices for the VM display as a list.

Device notes:

A virtual machine attempts to boot from devices according to the Device Order, starting with 1000, then ascending.
A CD-ROM device allows booting a VM from a CD-ROM image like an installation CD. The CD image must be available in the system storage.
A Display device provides remote clients with a way to connect to VM display sessions.

See Adding and Managing VM Devices for more information.

Managing a Virtual Machine

After creating the VM and configuring devices for it, click on the VM to expand it and show the options to manage the VM.

An active VM displays options for Display and Serial Shell connections.

When a display device is configured, remote clients can connect to VM display sessions.

If the display connection screen appears distorted, try adjusting the display device resolution.

Use the Running toggle or click Stop to follow a standard procedure to do a clean shutdown of the running VM. Click Power Off to halt and deactivate the VM, which is similar to unplugging a computer.

If the VM does not have a guest OS installed, the VM Running toggle and Stop button might not function as expected. The Running toggle and Stop buttons send an ACPI power down command to the VM operating system, but since an OS is not installed, these commands time out. Use the Power Off button instead.

Installing an OS

After configuring the VM in TrueNAS and an OS .iso file is attached, start the VM and begin installing the operating system.

Some operating systems can require specific settings to function properly in a virtual machine. For example, plain Debian can require advanced partitioning when installing the OS. Refer to the documentation for your chosen operating system for tips and configuration instructions.

Installing Debian OS Example

Upload the Debian .iso to the TrueNAS system and attach it to the VM as a CD-ROM device. This example uses Debian 12 and basic configuration recommendations. Modify settings as needed to suit your use case.

Click Virtual Machines, then ADD to use the VM wizard. Configure settings as needed.
Figure 11: Add Debian VM

Settings used in this example

Operating System

Setting	Description
Guest Operating System	Linux
Name	debianVM
Description	Debian VM

CPU and Memory

Setting	Description
Memory Size	1024 MiB

Disks

Setting	Description
Create new disk image	Selected
Zvol Location	Select pool.
Size	30 GiB

Network Interface

Setting	Description
Attach NIC	Select the physical interface to associate with the VM.

Installation Media

The installation ISO is uploaded to local storage. If the ISO is not uploaded, select Upload an installer image file. Select a dataset to store the ISO, click Choose file, then click Upload. Wait for the upload to complete.

GPU

Leave the default values.

Confirm Options

Verify the information is correct and then click Save.

After creating the VM, start it. Expand the VM entry and click **Start**.

Click Display to open a SPICE interface and see the Debian Graphical Installation screens.
Press Enter to start the Debian Graphical Install.
a. Enter your localization settings for Language, Location, and Keymap.
b. Debian automatically configures networking and assigns an IP address with DHCP.
- If the network configuration fails, click Continue and do not configure the network yet.
c. Enter a name in Hostname.
d. Enter a Domain name.
e. Enter the root password and re-enter the root password.
f. Enter a name in New User.
g. Select the username for your account or accept the generated name.
h. Enter and re-enter the password for the user account.
j. Choose the time zone, Eastern in this case.
Detect and partition disks.
a. Select Guided - use entire disk to partition.
b. Select the available disk.
c. Select All files in one partition (recommended for new users).
d. Select Finish partitioning and write changes to disk.
e. Select Yes to Write the changes to disks?.
Install the base system:
a. Select No to the question Scan extra installation media.
b. Select Yes when asked Continue without a network mirror.
Install software packages:
a. Select No when asked Participate in the package usage survey.
b. Select Standard system utilities.
c. Click Continue when the installation finishes.
After the Debian installation finishes, close the display window.
Remove the device or edit the device order. In the expanded section for the VM, click Power Off to stop the new VM.
a. Click Devices.
b. Remove the CD-ROM device containing the install media or edit the device order to boot from the Disk device.
- To remove the CD-ROM from the devices, click the and select Delete. Click Delete Device.
- To edit the device boot order, click the and select Edit. Change the CD-ROM Device Order to a value greater than that of the existing Disk device, such as 1005. Click Save.
Return to the Virtual Machines screen and expand the new VM again.
Click Start, then click Display.

What if GRUB does not start automatically?

If GRUB does not run when you start the VM, enter the following commands after each start. At the shell prompt:

Enter FS0: and press Enter.
Enter cd EFI and press Enter.
Enter cd Debian and press Enter.
Enter grubx64.efi and press Enter.

To ensure it starts automatically, create the startup.nsh file at the root directory on the VM. To create the file:
Go to the Shell.
At the shell prompt, enter edit startup.nsh.
In the editor, enter:
a. Enter FS0: and press Enter.
b. Enter cd EFI and press Enter.
c. Enter cd Debian and press Enter.
d. Enter grubx64.efi and press Enter.
Use the Control+s keys (Command+s for Mac OS) then press Enter.
Use the Control+q keys to quit.
Close the display window
To test if it boots up on startup:
a. Power off the VM.
b. Click Start.
c. Click Display.
d. Log into your Debian VM.

Configuring Virtual Machine Network Access

Configure VM network settings during or after installation of the guest OS. To communicate with a VM from other parts of your local network, use the IP address configured or assigned by DHCP within the VM.

To confirm network connectivity, send a ping to and from the VM and other nodes on your local network.

Debian OS Example

Open a terminal in the Debian VM.

Enter ip addr and record the address.

Enter ping followed by the known IP or hostname of another client on the network, that is not your TrueNAS host. Confirm the ping is successful. To confirm internet access, you can ping a known web server, such as ping google.com.

Accessing TrueNAS Storage From a VM

By default, VMs are unable to communicate directly with the host NAS. If you want to access your TrueNAS SCALE directories from a VM, for example, to connect to a TrueNAS data share, you have multiple options.

If your system has more than one physical interface, you can assign your VMs to a NIC other than the primary one your TrueNAS server uses. This method makes communication more flexible but does not offer the potential speed of a bridge.

If your system has only one physical interface, create a bridge interface for the VM to use. Stop all existing apps, VMs, and services using the current interface, edit the interface and VMs, create the bridge, and add the bridge to the VM device. See Accessing NAS from VM for more information.

Migrating Containers VMs

The storage volumes (zvols) for virtual machines created using the Instances screen in TrueNAS 25.04.0 or 25.04.1 (renamed the Containers screen in 25.04.2 and later) can migrate to new VMs created using the Virtual Machines screen in 25.04.2 and later. The process involves:

Identifying the hidden storage volumes (zvols) associated with the Instance VMs.
Determining which zvol contains the actual VM data by checking the volume size.
Renaming (and moving) the zvols to a new dataset where they can be seen and used by a new VM.
(Highly Recommended) Configuring zvol properties to match those of natively-created VM zvols.
Creating a new VM and selecting the migrated zvol as the storage volume.

Before You Begin

Before beginning the process:

Identify the zvol names associated with the Instance (Container) VM.
Take a recursive snapshot or back up the pool configured for Instance VMs. Using ZFS commands to rename and move an existing zvol can damage data stored in the volume. Having a backup is a critical step to restoring data if something goes wrong in the process.
Verify the VM is operational and the network is functioning as expected. One way to do this is to verify it has Internet access. Then stop the VM before you upgrade to the next release.
Identify the dataset where you want to move the volume. We do not recommend renaming or moving the volume more than once, as it increases the risk of possible data corruption or loss.

You do not need to log in as the root user if the logged-in admin user has permission to use sudo commands. If not, go to Credentials > Users, edit the user to allow sudo commands, or verify the root user has an active password to switch to this user when entering commands in the Shell screen.

Migrating a Zvol for an Instance VM

This procedure applies to the zvol for an Instance or Container VM that has data you want to preserve and access from a new VM using the Virtual Machines screens in later releases.

Go to Instances (or Containers), click on Configuration, and then Manage Volumes to open the Volumes window. The Volumes window lists all Instances VMs and associated storage volumes (zvols).
Record the volume name or take a screenshot of the information to refer to later when entering commands in the Shell screen. Zvol names are similar to the VM name but not identical. Optionally, you can highlight all the listed information and copy/paste it into a text file, but this is not necessary.
While on the Instances screen, verify the VM is operational and the network is operating as expected. One way to verify external network access is to check Internet access. Stop the VM before upgrading. Repeat for each zvol that you plan to migrate into a new VM in later releases.
Go to Datasets, locate the pool associated with Instances (Containers), and take a recursive snapshot to back up all Instances VM zvols. These zvols are in the hidden .ix-virt directory created in the pool Instances uses, selected when you configure the feature. To verify the pool, you can go to Containers > Configure > Global Settings and look at the Pool setting.
Go to System > Update, and update to the next publicly available maintenance or major version release. Follow the release migration paths outlined in the version release notes or the Software Releases article.
After updating to a 25.04.x release or later, VMs created using Instances screens show on the Containers screen, and are stopped. Some VMs experience various issues like network connectivity, or are stopped and do not start. Refer to the troubleshooting tips below for more information. 25.10 releases correct some issues encountered in 25.04.2.4 VMs that are migrated.

After upgrading to a release that shows the Virtual Machines screen and the Containers option:

Go to Containers to see which VMs are listed, then click Configuration, and then Manage Volumes to open the Volumes window. Take a screenshot of the volumes listed, or copy/paste the volumes and VM information into a text file to use later in this procedure. Zvol names are similar to the VM but not identical. Volume names are used in step 6 below.
Go to System > Shell. Exit to the Linux prompt for the system.
Note: This is where the logged-in admin user needs sudo permissions, or where the root user must have a password configured to enter the following commands to find, rename/move, and verify each Instance zvol is properly configured. Experienced users can switch to the root user if the root user has a password assigned and enabled.
Enter the following commands at the Linux system prompt:
Storage conventions differ based on VM history:
- Migrated VMs (from pre-Incus TrueNAS) use custom/default_* zvols for actual VM data
- VMs created in 25.04.0 or 25.04.1 use .block zvols for actual VM data
- Small .block files (56K) are stubs and should not be migrated
a. Locate the hidden zvols for the Instance VMs, by entering:
sudo zfs list -t volume -r -d 10 poolname
Where:
- -d 10 shows datasets up to 10 levels deep
- poolname is the name of the pool associated with the Instance VMs. If you have multiple pools associated with the Instance VMs, repeat this command with the name of that pool to show hidden zvols in that pool.
The .ix-virt directory contains the zvols used in Instance VMs. Check the USED or REFER columns to identify the actual VM storage:
- For migrated VMs: Use the custom/default_* zvol (typically several GB or more)
- For VMs created in 25.04.0 or 25.04.1: Use the .block zvol that shows significant storage usage (not 56K stubs)
- Ignore: Stub .block files showing only 56K, and zvols not in the .ix-virt directory
The output includes other zvols in the pool if your system has non-instance VMs configured in the pool name entered in the command.
Example Command Output
Example showing migrated VMs (custom/ zvols with actual data):
```
re-minir-102% sudo zfs list -t volume -r tank
NAME                                                               USED  AVAIL  REFER  MOUNTPOINT
tank/.ix-virt/custom/default_vm2410linux-8cppg                   40.6G  1.66T  40.6G  -  ← Migrate this (actual data)
tank/.ix-virt/custom/default_vm2410win-mvqznj                    40.2G  1.66T  40.2G  -  ← Migrate this (actual data)
tank/.ix-virt/virtual-machines/vm2410linux.block                   56K  1.66T    56K  -  ← Stub (ignore)
tank/.ix-virt/virtual-machines/vm2410win.block                     56K  1.66T    56K  -  ← Stub (ignore)
tank/vms/previously-migrated                                     35.1G  1.70T  35.1G  -
```
Example showing VMs created in 25.04.0/25.04.1 (.block zvols with actual data):
```
qe-realmini% sudo zfs list -t volume -r tank
NAME                                                              USED  AVAIL  REFER  MOUNTPOINT
tank/.ix-virt/virtual-machines/TrueNAS.block                     6.98G  2.55T  6.98G  -  ← Migrate this (actual data)
tank/.ix-virt/virtual-machines/fdsa.block                        25.9M  2.55T   248M  -  ← Migrate this (actual data)
tank/.ix-virt/virtual-machines/debian.block                        56K  2.55T    56K  -  ← Stub (ignore)
tank/.ix-virt/virtual-machines/mint.block                          56K  2.55T    56K  -  ← Stub (ignore)
```
In the examples above:
- Zvols with custom/default_* in the path showing significant storage (40+GB) are migrated VMs to migrate
- Zvols with .block extension showing significant storage (6.98G, 25.9M) are native Incus VMs to migrate
- Small .block files at 56K are stubs and should be ignored
After successfully migrating and confirming functionality of all VMs, the remaining stub .block files (56K) in .ix-virt/virtual-machines/ can optionally be deleted to clean up the hidden dataset.
b. Rename (and move) each volume in the .ix-virt directory to a new location where you can select it when configuring a new VM. Repeat for each volume you want to migrate to a new VM. Do not rename or move stub .block files (56K).
For migrated VMs (custom/ zvols):
sudo zfs rename tank/.ix-virt/custom/default_debian1-urec9f tank/vms/default_debian1-urec9f
For VMs created in 25.04.0 or 25.04.1 (.block zvols with actual data):
sudo zfs rename tank/.ix-virt/virtual-machines/TrueNAS.block tank/vms/TrueNAS.block
Where:
- tank is the pool name in the examples.
- default_debian1-urec9f or TrueNAS.block is the name of a hidden zvol in the examples, and the name given to the migrated zvol. We do not recommend renaming the migrated zvol to minimize potential issues with the migration process. For .block zvols, you can keep or remove the .block extension in the target name.
- vms is the dataset in the examples as the location to store the migrated zvols for VMs. Change this to the location on your system.
This renames and moves it to the specified location, and returns to the system Linux prompt. To verify the zvol moved, enter the sudo zfs list -t volume -r tank command again. The output should show the zvol in the new location.
c. (Highly Recommended) Set zvol properties to match those of natively-created VM zvols. Enter the following command for each zvol you migrated:
For migrated VMs (custom/ zvols):
sudo zfs set volmode=default primarycache=all secondarycache=all tank/vms/default_debian1-urec9f
For VMs created in 25.04.0 or 25.04.1 (.block zvols):
sudo zfs set volmode=default primarycache=all secondarycache=all tank/vms/TrueNAS.block
Where:
- tank is the pool name.
- vms is the dataset where the zvol is stored.
- default_debian1-urec9f or TrueNAS.block is the name of the zvol
This command sets the volume properties to match those used by zvols created through the Virtual Machines screen, ensuring optimal performance and behavior. Containers VMs used different property settings that are not optimal for virtual machine workloads.
After completing the commands listed above for each zvol you want to migrate, go to Datasets and verify all volumes you migrated show on the screen.
Create the new VM using the migrated zvol. Repeat these steps for each zvol you migrated.
Go to Virtual Machines, click on Add to open the Create Virtual Machine wizard. For more information or details on using the Create Virtual Machine wizard, see Creating a Virtual Machine.
a. Complete the first screen by entering a name for the new VM, select the operating system used by the Instances VM, enter a brief description, and then if using the Bind setting, enter a password. Click Next.
b. Configure the CPU and Memory settings, and then click Next.
c. On the Disks wizard screen, select Use existing disk image, click in Select Existing Zvol and select the volume moved from the Instances VM. If you move multiple zvols, refer to the screenshot or text file with the VM/zvol list to select the correct zvol for this new VM.
d. Click Next until you get to the confirmation screen, then click Create to add the VM.
After adding the new VM, click on the row to expand it, and click Devices. Click Edit for the Disk device, and enter 1000 in the Device Order field. Setting the disk to 1000 makes the disk device the first in the boot order for the VM. Setting the disk to first in boot order over a CD-ROM device with an OS on it, if added when creating the VM, prevents the volume from being overwritten by booting from that CD-ROM device. Click Save.
Return to the Virtual Machines screen, expand the VM, then click Start to verify it opens as expected and has network access.
